    Vaccum Freeze Dryer Series

Vacumm freeze dryer is widly used in medicine,pharmacy,biology research,chemical industry and food production etc. Goods are easier for long-term preservation after freezing-drying processing.They can be restored to the orginal state and maintain its chemical and biological characteristics after being watered.
SJIA-10N,SJIA-12N,SJIA-18N this series has five types: ordinary, top-press, multi-pipeline ordinary,multi-pipeline top-press and T-type shelf

Advantages of SJIA- N Freeze Dryer

1. Refrigeration uses Linde-hampson, the world's leading technology, with a refrigeratory (secondary cooling by refrigeration), high refrigeration efficiency;

2. The use of environmentally friendly refrigerants (absolutely does not contain the refrigerants banned by the state, some manufacturers still use the mixed refrigerant scheme with the ratio of R12 and R22 banned by the state);

3. Refrigeration temperature:

3.1 Temperature of cold trap up to standard (no load): <60 (DegC) and room temperature <28 (DegC)

3.2 Limit cold trap temperature (no load): <65 C, room temperature <25 C;

4. Using a 7-inch touch screen, the display is intuitive and easy to operate, without defining the inexplicable button selection.

5. Support freeze-drying data curve recording function.

6. The requirement of cold trap temperature can be set when the vacuum pump starts, so as to avoid starting the vacuum pump when the cold trap temperature does not reach the effective low-temperature water catching performance, resulting in water entering the vacuum pump.

7. With an additional set of sensors, it can be used to measure sample temperature and record data.

8. Temperature and vacuum have correction function.

9. Switching unit with vacuum pressure display, supporting Mbar (millibar), Pa (Pascal), Torr (Toll).

10. Free upgrade of electric defrosting function

Model	SJIA-18N
Parameters Model		SJIA-18N-60A Basic type	SJIA-18N-60B Top-down	SJIA-18N-60C Manifold	SJIA-18N-60D Top down&manifold	SJIA-18N-60E T type
Drying area	㎡	0.27	0.092	0.27	0.092
Tray	mm	240*4	200*3	240*4	200*3
Tray capacity Condensor No-load temperature	L	2	1.5	2	1.5
Tray capacity Condensor No-load temperature	℃	<-60 (-80 optional ）
Vacuum	Pa	<10pa
Interlayer spacing	mm	70
Vals number for reference	22	360	270	360	270
	16	740	560	740	560
	12	1320	990	1320	990
Ability to capture water	Kg	6kg/24H
voltage	V/Hz	220V/110V
Power	W	850W
Machine size	mm	800530730
