1.Details

The TP511-YZ35 is a high-precision filling peristaltic pump, ideal for high-volume filling applications. It features a maintenance-free DC brushless servo motor with closed-loop control. The housing is made of metal with a special surface coating for easy cleaning and corrosion resistance. The pump supports volume setting, time setting, suction angle adjustment, volume calibration, priming, batch counting, power-off memory, no-bottle-no-filling, and batch filling. The user interface offers a bilingual menu (Chinese and English), and allows users to select acceleration/deceleration curves to prevent splashing and foaming, and to set suction angles to prevent dripping.

Typical Applications

Ÿ High-volume liquid transfer

Ÿ Lyophilized powder injection filling

Ÿ Diagnostic reagent dispensing

Compatible Tubing
73#, 82#

2.Advantages

Ÿ Special surface coating for easy cleaning and corrosion resistance

Ÿ Maintenance-free high-torque DC brushless servo motor with closed-loop control for smooth operation

Ÿ Large LCD display with bilingual menu, calibration software, and step-counting operation

Ÿ Relay trigger control for filling and startup, with no-bottle-no-filling functionality

Ÿ High-precision dispensing with accuracy ≤ ±0.5%

Ÿ Multiple control modes with built-in RS485 interface

3.Specification

Item	Description
Speed Range	0.1-600 rpm
Speed Resolution	0.1 rpm
Motor Type	Brushless DC Servo Motor
Noise Level	≤70 dB (measured 30 cm in front of the product)
Power Supply	100~240 VAC 50/60 HZ
Power Consumption	≤300 W
Driver Weight	11 kg
Display Type	LCD screen displaying operating parameters and status; bilingual menu (Chinese/English) available
Control Method	Front panel buttons for parameter adjustment, with buzzer sound prompts
External Control Interface	Speed control via 4-20 mA current or 0–10 V voltage signals; RS485 interface with Modbus RTU communication protocol
Protection Rating	IP66
Operating Environment	Temperature 0–40 °C; Relative Humidity <80%
