Flow Metering Peristaltic Pump TP201-KZ15 price

Product Detail
Company Profile

1.Details

The TP201-KZ15 is a flow metering peristaltic pump featuring a streamlined metal-formed housing with a special surface coating for easy cleaning and corrosion resistance. It is driven by an integrated stepper motor for quiet operation. The pump supports multi-head serial connection, enabling higher delivery pressure. Key functions include tubing selection and flow calibration, power-off memory, quick priming and draining, and a key lock function.

Typical Applications

Laboratory fluid dosing and metered reagent feeding in chemical reactions
Infusion pumping in harsh environments

Compatible Tubing

13#, 14#, 19#, 16#, 25#, 17#

2.Advantages

Compact size, space-saving design, highly portable
Large LCD display for clear and intuitive operation
Aluminum alloy housing with special coating for corrosion resistance and easy cleaning
Two working modes: quantitative filling and continuous working, offering flexibility for various scenarios
Integrated stepper motor ensures smooth, low-noise operation
High-torque motor supports multiple pump head types
Power-off memory function can store up to 16 parameter sets for quick recall and improved efficiency

3.Specification

Item	Description
Speed Range	1-600 rpm
Speed Resolution	0.1 rpm
Motor Type	Integrated stepper motor
Noise Level	≤65 dB (measured 30 cm in front of the device)
Power Supply	100-240 VAC 50/60 HZ
Power Consumption	≤50 W
Drive Weight	52 KG
Display Mode	LCD screen displays operating parameters and working status; Chinese/English menu optional
Operation Mode	Panel buttons for parameter setting and adjustment; buzzer for alerts
External Control Mode	Compatible with round 9-pin aviation connector; supports multiple control modes including RS485 interface (Modbus RTU protocol)
Protection Rating	IP54
