Batch Transfer Peristaltic Pump TP601-TH35 price

Product Detail
Company Profile

1.Details

TP601-TH35 is a batch transfer type peristaltic pump. The chassis is made of aluminum alloy with a special surface coating, which is corrosion-resistant and easy to clean. It uses an AC servo motor and driver, offering high speed accuracy, precise positioning, automatic torque adjustment, and strong power. The pump is equipped with large-diameter thick-walled tubing. It features external control interfaces with multiple control modes, flow display function, capable of metering and quantitative dispensing. The TH35 pump head is a dual-roller spring peristaltic design, which reduces shear force on the tubing and extends tubing life. The pump head is made of aluminum alloy with a special surface coating suitable for pharmaceutical sterilization.

Typical Applications

Ÿ Large-volume pharmaceutical liquid transfer

Ÿ High-head feeding in chemical processes

Compatible Tubing
73#, 82#, 184#

2.Advantages

Ÿ Chassis with special surface coating for corrosion resistance and easy cleaning

Ÿ Dual-roller spring pump head design reduces shear force and extends tubing life

Ÿ Driven by AC servo motor with high precision, accurate positioning, self-adjusting torque, and strong power, suitable for large-diameter thick-walled tubing

Ÿ Two modes: quantitative filling or continuous working, offering strong flexibility

Ÿ Large LCD screen with Chinese and English menus, calibration software, full step counting operation, and three-level access control management

3.Specification

Item	Description
Speed range	1-360 rpm
Speed resolution	0.1 rpm
Motor type	Brushless DC servo motor
Applicable power supply	100~240 VAC 50/60 HZ
Power	≤500 W
Driver weight	18.9 KG
Display method	LED LCD display
Operation method	Button adjustment
External control method	Control start/stop, direction, and speed via RS232 and RS485; dry contact signal controls start/stop; analog signals (current 4-20 mA, voltage 0-5 V, 0-10 V)
Protection level	IP66
Working environment	Temperature: 0~40℃; Relative humidity: <80%
