1.Details

The TP311-TH16 is a high-flow, spring-loaded peristaltic pump. The driver features a streamlined, metal-formed housing with a compact and attractive design. Its specially coated surface is easy to clean and well-suited for disinfection and sterilization in pharmaceutical environments. The pump uses a maintenance-free brushless DC motor for quiet and stable operation.

It is equipped with a large LCD screen that clearly displays various parameters, with optional Chinese/English menu settings. It offers two operating modes—quantitative filling and continuous working — for maximum flexibility.

The TH16 pump head is a high-flow, dual-rotor spring-loaded head. Its spring-driven dual-roller assembly significantly reduces shear force, thereby extending the lifespan of the tubing and minimizing damage to sensitive fluids like cell cultures.

This model is part of a flow-metering peristaltic pump series with features like tubing selection, flow calibration, power-off memory, fast priming/draining, and a key lock function. It also supports multi-head series connection for higher delivery pressure.

Typical Applications

Biologics / Vaccines

Compatible Tubing

18#, 16#, 25#, 17#

2.Advantages

Streamlined metal housing with a sleek and modern appearance
Special surface coating for corrosion resistance and easy cleaning
Large LCD screen for clear display of parameters; includes power-off memory function
Two working modes: quantitative filling and continuous working, suitable for various scenarios
Brushless servo motor with closed-loop control ensures smooth and stable operation
Spring-loaded pump head design significantly reduces shear force, protecting cells and prolonging tubing life

3.Specification

Item	Description
Speed Range	0.1-600 rpm
Speed Resolution	0.1 rpm
Motor Type	Brushless DC motor
Noise Level	≤65 dB (measured 30 cm in front of the device)
Power Supply	100-240 VAC 50/60 HZ
Power Consumption	≤150 W
Display Mode	LCD screen displays operating parameters and working status; Chinese/English menu optional
Operation Mode	Panel buttons for parameter adjustment; buzzer for audible alerts
External Control Mode	DB15 external control interface; Dry contact signals for start/stop and direction control; Analog signals: current (4–20 mA) or voltage (0–10 V) for speed control; RS485 interface with Modbus RTU protocol for control of start/stop, direction, and speed
Protection Rating	IP54
Operating Environment	Temperature 0–40°C; Relative humidity <80%
