1.Details

The LP101-YZ15 is a basic variable-speed peristaltic pump designed for fundamental laboratory applications. It is primarily used for continuous material transfer. The speed is adjustable within the range of 1 to 200 rpm. Featuring a compact design, low noise level, and smooth motor operation, it supports RS485 communication and analog signal control (4–20 mA, 0–10 V), offering multiple control modes.

Typical Applications

Laboratory liquid transfer
Reagent dosing
Acid/base addition in bioreactors

Compatible Tubing

14#, 19#, 16#, 25#, 17#

2.Advantages

Compact structure with a small, aesthetically pleasing design
Lightweight and highly portable
Integrated stepper motor ensures stable, low-noise operation
Die-cast aluminum housing with special surface coating for corrosion resistance and easy cleaning
Supports RS485 communication and analog signal control (4–20 mA, 0–10 V) for versatile control options

3.Specification

Item	Description
Speed Range	1~200 rpm
Speed Resolution	0.1 rpm
Motor Type	Integrated stepper motor
Noise Level	≤65 dB (measured 30 cm in front of the device)
Power Supply	24 VDC
Power Consumption	≤50 W
Drive Weight	3.4 KG
Display Mode	4-digit LED display showing speed, parameters, and other information; three LED indicators for forward/reverse direction and start/stop status
Operation Mode	Four tactile buttons for adjusting pump parameters and controlling start/stop functions
External Control Mode	Start/stop and direction controlled via dry contact signals; Speed controlled via analog signals (4–20 mA / 0–10 V); Start/stop, direction, and speed controlled via RS485 or RS232 communication protocols
Protection Rating	IP54
