Electrolyzed Oxidizing Water Generator/Acidic Oxidation Potential Water Generator ZYEOW,Sichuan Zhuoyue Water Treatment Equipment Co.,Ltd._specification/price/image

Product Detail
Company Profile

Products Description

ZYEOW electrolyzed oxidizing water generator electrolyzed oxidizing water is a safe and environmentally friendly electrolyte solution is electrolyzed.Adding electrolyte in raw water,the water will be electrolysis in through the diaphragm cell, then will generate acidic aqueous solution which main content is Hypochlorous (HCIO) and at last we will get EOW(Full name:Electrolyzed oxidizing water/Hypochlorous water).

sterilization effect of killing microorganism

kill object	cleaned items		unwashed items
kill object	Sterilization time (min)	Logaritmic value of disinfection	Sterilization time (min)	Logaritmic value of disinfection
Staphylococcus aureus ATCC6538	1.0	≥5.00	1.0	≥5.00
E. Coli F.8099	1.0	≥5.00	1.0	≥5.00
Candida albicans ATCC10231	1.0	≥5.00	1.0	≥4.00
Pseudomonas aeruginosa ATCC 15442	1.0	≥5.00	1	≥5.00
Bacillus subtilis var niger spores ATCC9372	15	≥5.00	/	/
poliovirus Type I vaccine strains	5.0	≥4.00	10.0	≥4.00

Model list

Modle	ZYEOW-Q1	ZYEOW-Q2	ZYEOW-Q3
Eow production	1000ml/min±10%	2000ml/min±10%	3000ml/min±10%
EOW index	Main bactericidal factor: hypochlorous acid Effective chlorine content: 50mg/L～70mg/L PH value: 2.0～3.0 Oxidation-reduction potential (ORP) ≥ 1100 mV Residual chloride ion should be <1000mg/L
water inlet requirements	Inlet water pressure: 0.2~0.3MPa; inlet water quality: soft water or pure water (pure water is preferred)；
Electrolyte	Liquid B：300G/bag	Liquid B：2000G/bag
Power supply	220V/50HZ
Power	≤800W	≤1200W	≤1500W
Size	500420590mm	6006001550mm	6006001550mm
Acid water tank	/	40L*2 (built-in)	40L*2 (built-in)

Product features

1. The system has PLC automatic program control and LCD touch screen operation. 2.The system has the function of displaying parameters,such as PH online,active chlorine content,electrolytic current and total working time. 3. The system is with automatic cleaning function so that to prolong the service life. 4.The alarm will sound when the electric current is too large or the raw water is not enough,so that to ensure the operation of the equipment.


Product exhibition

Sichuan Zhuoyue Water Treatment Equipment Co.,ltd is a integrated water treatment manufacturer with scientific research, design, production, sales, installation,after-sales services in Chengdu City, Sichuan Province, China, specializing in the production of laboratory ultra-pure water machine, medical water machine, pure /ultra-pure water equipment,water softener and other related water treatment equipment. Our 1500㎡modern factory is located in Rongzhi Innovation Industrial Park at Pixian modern industrial road, While 300㎡Sales Department office is located in Jinfu International Building, Jinniu District. Nowadays, the number of company staff is up to 100 and more. And also a complete after-sales service network is set up all over the country.
