- Freeze-dryer is a technical approach which can freeze the water-bearing materials in advance, and then sublime the water in the vacuum distillation to get the dry goods. After freeze-drying the items will be easier for long-term preservation, water could make it back to the pre-state and maintain the original chemical and biological characteristics. For the thermal material, such as antibiotics, vaccines, blood products, enzyme hormones and other bio-products, freeze-drying technology can show its superiority.
SYCLON series of freeze-dryer, double-barrel structure of the freeze-dried in situ (patent). It changed the traditional complicated operation to prevent the pollution of the material. It makes the drying process automation and be suitable for unit production.
SYCLON series of freeze-dryer with heating shelf programmable control and PID regulation can accurately control temperature. Human-computer interface with large-screen LCD, the curve and data makes more freeze-drying process information available.
Characteristic:
The process of pre-freezing and drying finishes in situ. The freeze dryer is equipped with observation windows and the drying process is intuitive.
LCD display and PID regulation.
Touching-screen operation, PID controlling, displaying drying curve.
The sample tray is square so it’s easy to clean and operate.
The drying chamber adopts transparent organic glass door the changing process of material is clear.
The drying chamber adopts transparent organic glass door the changing process of material is clear.
| Model /Specification | SJIA-20F | SJIA-30F | SJIA-50F | SJIA-100F | SJIA-200F | SJIA-300F |
| Freeze-drying area(m2) | 0.24 | 0.3 | 0.5 | 1 | 2 | 3 |
| Water capture capability（kg/24H） | 6kg | 7kg | 10kg | 15kg | 30kg | 50kg |
| Cold trap temperature（℃） | <-75℃ | |||||
| Vacuum (Pa)） | <10PA | |||||
| Shelves temperetarure（℃） | -50℃~+65℃ | |||||
| Trays number | 2+1 | 3 | 3+1 | 6+1 | 5+1 | 6+1 |
| Tray size (mm) | 300*400 | 280x400 | 500x360 | 500x360 | 500*900 | 600*850 |
| Tray cacity（L） | 6L | 7L | 10L | 15L | 30L | 50L |
| Dia vails Ø12mm (reference) | 2000 | 2600 | 3600 | 7920 | 11000 | 16000 |
| Dia vails Ø16mm(reference ) | 960 | 1440 | 2000 | 4092 | 8000 | 12000 |
| Valovs Ø22mm(reference) | 660 | 728 | 1050 | 2112 | 4000 | 6000 |
| Top down | Automatic hydraulic pressure | |||||
| voltage | 220V 50HZ | 380V 50HZ | ||||
| Machine size（mm) | 1100*900*1280 | 915*1245*1700 | 1100*900*1900 | 2100*1200*2200 | 3000*1200*2300 | 4500*2300*3100 |
| (L*W*H) | ||||||
| weight（kg) | 350kg | 450kg | 650kg | 1050kg | 300kg | 4500kg |
| power（W） | 1.8kw | 2.5kw | 3.5kw | 7kw | 10kw | 20kw |
Silicone Oil Heating Freeze Dryer Technical indicators
| Model /Specification | SJIA-5F | SJIA-2S | SJIA-3S | SJIA-5S |
| Freeze-drying area(m2) | 0.1 | 0.24 | 0.36 | 0.48 |
| Water capture capability（kg/24H） | 2kg/24h | 3kg/24h | 4kg/24h | 5kg/24h |
| Cold trap temperature（℃） | <-50℃ |
<-60℃ |
||
| Vacuum(Pa)） | <15PA | |||
| Tray temperature（℃） | -40℃~+50℃ | -50℃~+60℃ | ||
| Tray number | 1 | 2 | 3+1 | 4+1 |
| Tray size(mm) | 280*400 | 300*400 | 300*400 | 300*400 |
| Tray capacitys（L） | 1L | 3L | 3L | 5L |
| Vails Ø12mm (reference) | 700 | 1600 | 2400 | 3200 |
| vailsØ16mm(reference) | 300 | 700 | 1050 | 1400 |
| Vails Ø22mm(reference ) | 200 | 500 | 1000 | 1500 |
| Top down | Automatic (optional) | no | ||
| voltage | 220V 50HZ | |||
| Machine size（mm) | 880*660*550 |
850*760*1250 | 880*665*1163mm | 880*665*1163mm |
| (L*W*H) | ||||
| weight（kg) | 80kg | 200kg | 230KG | 250KG |
| power（about W） | 1.3KW | 1.5kw | 2.2kw | 3kw |
-
