Lab Spray Dryer
Description
Spray drying is through mechanical action, disperse the material into very fine mist-like particles
(To increase the evaporation area of water and accelerate the drying process），after contact with hot air, most of the moisture is removed in an instant, and the solid matter in the material is dried to a powder.
Feature
●The whole machine is made of 304 stainless steel, and the atomization structure of the two-fluid spray (precision manufactured by high-quality stainless steel material, compact design, no need for auxiliary equipment, convenient use, long time as new);
●Real-time regulation of PID thermostatic control technology (heating temperature, inlet air velocity, peristaltic pump feed rate can be adjusted at any time);
●LCD touch screen operation control, Chinese and English operation interface.
●The spray head is located in the middle of the drying chamber and can be dried in parallel or counter currently.
●The diameter of the dusting powder is normally distributed, the fluidity is very good, and the noise is very low, in line with the national laboratory noise standard.
●The latest improvement of the external air compressor, the noise is smaller, the whole machine is stable and vibration-free!
●The two-fluid atomizer has a built-in needle anti-blocking design;
I Technical Parameters
Air Inlet Temperature Range: 30 to 300℃（Test temperature 150~300℃）
Outlet temperature observation: 30 to 140℃
Max Evaporation: 5000 ml/H
Electric Heating Power: 6.5KW/AC220V/Single phase ground(380V 7.5KW)
Fan: 0.2KW; Max Airflow: 10 m³/min; Max Air Pressure: 686Pa
COMPA Working Pressure: 2-5Bar
Air compressor: 0.85KW
Dimensions: 1850mm (H) × 1300mm (L) × 1300mm (W)
Diameter of Spray Nozzle: 1.0mm
Weight: 240KG
-
