Ultrasonic Nanoparticles Material Disperser for Homogeneous Emulsifer,Shanghai Leewen Scientific Instrument Co.,Ltd._specification/price/image

Industry and Laboratory Ultrasonic Nanoparticles Material Disperser for Homogeneous Emulsifer

Model	LW-500	LW-1000	LW-1500	LW-3000
Power ratio	5~500W adjustable	10-1000W (Adjustable)	15-1500W (Adjustable)	1000-3000W Manual adjustable
Crushing capacity	0.1-400ML(according to the horn)	0.1-700ML(need to match the corresponding horn)	1-1500ML(need to match the corresponding horn)	500-5000ML(need to match the corresponding horn)
Display method	4.3 inch touch screen
Single ultrasound time
Single gap time	0.1-99.9S
Total time (ultrasound + gap)	1-99H59M59S
Frequency Range	20-25KHz		19.5-20.5KHz
Temperature control range	0-100℃(option Low temperature thermostat)
Alarm function	Time, overload, no load, over temperature
Random horm	Φ6(mm)	Φ6(mm)	Φ22(mm)	Φ40 Lengthened(mm)
Optional horn	Φ2,3,10,12(mm)	Φ2,3,8,10,12,15(mm)	Φ3,6,10,15,20,25(mm)	Φ20,35,38,40 Lengthened,50(mm)
Data storage	20 groups
power supply	220V/110V/ 50Hz/60HZ
Net Size (LWH)	410225290(mm)			510225290(mm)
Net Weight Controller	12kg		16kg	17kg
Gross Weight Controller	16kg		19kg	21kg
Packaging Size	470305430(mm)
Soundproof box gross weight	10kg			15kg
packing of soundproof box (L * W *H)	350350550(mm)			430415730(mm)
Voice alarm and prompt function	Yes
Continuous ultrasound function	No
