Features
• Compact, cost-efficient and easy - to- use
• Excellent precision and reliability
• Long life, high performance, maintenance –free electrodes
• Automatic sampling, washing and calibration
• Touch screen ,large LCD display
• Internal thermal recorder，supporting barcode reader
• Auto sampler optional
Specifications
Principle:Direct measurement by Ion Selective Electrode (ISE)
Sample: Whole blood, serum, plasma, diluted urine
Sample volume:100~150µL
Throughput: up to 60 samples/h
Data storage: up to 200 patient result
Calibration: Automatic or On-demand
Input:Touch-screen
Display: Large LCD with backlight
Output: Internal thermal recorder, RS-232 serial port
Working Environment: Temperature: 15ºC~32ºC
Relative humidity: 85%
Input voltage: AC 220V/110V ±10%, 50/60Hz
Power consumption: 60W
Dimensions: 440mm×380mm×350mm (H×W×D)
Weight :Main unit –10kg
Auto sampler (option) – 1.5kg
Simple and reliable design of fluid tubing system and electrodes, minimize the maintenance work
Automatic sampling and probe washing, Minimize the carry-over
Touch screen , user friendly software , easy to operate
|
Measuring range |
Reproducibility(CV%) |
|
K+ |
0.50~15.00 mmol/L |
≤1.5% |
|
Na+ |
30.0~200.0 mmol/L |
≤1.0% |
|
Cl- |
30.0~200.0 mmol/L |
≤1.5% |
|
Ca2+ |
0.10~5.00 mmol/L |
≤2.0% |
|
Li+ |
0.20~3.00 mmol/L |
≤3.0% |
|
pH |
4.00~9.00 unit |
≤1.0% |
|
Measuring range |
Reproducibility(CV%) |
|
K+ |
0.50~15.00 mmol/L |
≤1.5% |
|
Na+ |
30.0~200.0 mmol/L |
≤1.0% |
|
Cl- |
30.0~200.0 mmol/L |
≤1.5% |
|
Ca2+ |
0.10~5.00 mmol/L |
≤2.0% |
|
Li+ |
0.20~3.00 mmol/L |
≤3.0% |
|
pH |
4.00~9.00 unit |
≤1.0% |
Different Models
XI-921F K+ / Na+ / Cl-
XI-921A K+ / Na+
XI-921B K+ / Na+ / Cl- / HCO3- / AG
XI-921C K+ / Na+ / Cl- / Ca2+ / pH
XI-921D K+ / Na+ / Cl- / Ca2+ / pH / HCO3- /AG
XI-921E K+ / Na+ / Cl- / Li+
