| Optical System Specifications |
|
Optical System |
Infinite |
| Tube Lens Focal Length |
200mm |
| System Optical Magnification |
40-1000X |
| Expandable System Optical Magnification(Optional Parts Required) |
40-1600X |
| Trinocular Optical Magnification |
4-100X |
| Standard Eyepiece |
10X High Eyepoint Eyepiece |
| Standard Objective |
4X 10X 40X 100X Infinity Plan Achromatic Objective |
| Standard Coupler |
1X |
| System Field of View |
Φ0.2-5mm |
| Expandable System Field of View |
Φ0.14-5.5mm |
| System Working Distance |
0.12-12.31mm |
| Expandable System Working Distance |
0.12-12.31mm |
| Compound Trinocular Head |
|
Eyetube Optical System |
Infinite |
| Eyetube Type |
For Compound Microscope |
| Eyetube Adjustment Mode |
Siedentopf |
| Eyetube Angle |
30° |
| Erect/Inverted Image |
Inverted Image |
| Eyetube Rotatable |
360° Rotatable |
| Interpupillary Adjustment |
50-75mm |
| Eyetube Inner Dia. |
Φ30mm |
| Eyetube Diopter Adjustable |
Left ±5°, Right Not Adjustable |
| Eyetube Size for Scope Body/Carrier |
Φ44.5x5mm |
| Image Port Switch Mode |
20/80 True-Trinocular |
| Surface Treatment |
Spray Paint |
| Material |
Metal |
| Color |
White |
| Net Weight |
1.03kg (2.27lbs) |
| Applied For |
BM0302 Series Microscope |
| Nosepiece |
|
Inward/Outward Nosepiece |
Nosepiece Inward |
| Number of Holes on Nosepiece |
Quadruple Holes |
| Nosepiece Switch Mode |
Manual |
| Nosepiece Screw Thread for Objective |
4/5″x1/36″ |
| Microscope Stand |
|
Stand Height |
300mm |
| Base Type |
Illumination Base |
| Base Shape |
Triangle |
| Base Dimensions |
280x185x65mm |
| Microscope handle |
Yes |
| Focus Mode |
Manual |
| Coarse/Fine Focus Type |
Coaxial Coarse/Fine Focus |
| Focus Distance |
20mm |
| Fine Focus Travel Distance |
Same as Focus Distance |
| Coarse Focus Distance per Rotation |
20mm |
| Fine Focus Distance per Rotation |
0.1mm |
| Fine Focus Minimum Scale |
1μm |
| Focus Limited |
Limited |
| Focusing Knob Tightness Adjustable |
Tightness Adjustable |
| Microscope Stage |
|
XY Stage Travel Distance |
75x50mm |
| XY-Axis Drive Mode |
Manual |
| Stage Platform Dimensions |
155x135mm |
| Stage Backlight Window Size |
29x80mm |
| Stage Scale |
X: -2-88mm Y: -2-65mm |
| Opening Size of Stage Specimen Holder |
Opening 55-95mm |
| Microscope Illuminator |
|
Illumination Type |
Halogen Transmitted Light |
| Transmission Light |
Kohler Illumination |
| Transmission Light Source Type |
Halogen Light |
| Field Diaphragm Mounting Position |
Vertical Illuminator |
| Field Diaphragm Adjustable |
Adjustable |
| Field Diaphragm Outer Dia. |
Φ71.5mm |
| Number of Filter Slots |
1 |
| Filter Switch Type |
Embedded Type |
| Condenser |
|
Condenser Type |
Abbe Condenser |
| Dry/Hydraulic Type |
Dry |
| Applicable Range of Objective |
4-100X |
| Condenser Adjustable |
Adjustable |
| Condenser Max. Numerical Aperture |
N.A. 1.25 |
| Condenser Mounting Flange Size |
Fastening Screw |
| Condenser Base Travel Distance on Z-Axis |
20mm |
| Surface Treatment |
Electroplating Black |
| Material |
Metal |
| Color |
Black |
| Net Weight |
0.10kg (0.22lbs) |
| Applied For |
BM0301, PH0302, BM0302, MT0302, FM0302 Series Microscope |
| 1X Coupler |
Coupler Mount Type for Trinocular |
Fastening Screw |
| Coupler Mount Size for Trinocular |
Φ36mm |
| Adjustable Coupler |
Adjustable |
| Coupler Magnification |
1X |
| For Camera Sensor Size |
Under 2/3″ |
| C/CS-Mount Coupler |
C/CS-Mount |
| Surface Treatment |
Electroplating Black |
| Material |
Aluminum |
| Color |
Black |
| Net Weight |
0.13kg (0.29lbs) |
| Applied For |
BM0301, PH0302, PL0302, BM0302, MT0302, PL0302, FM0302, BM0303, FM0303, MT0303 Series Microscope |
