Water bath,Ningbo YinZhou SjiaLab Equipment Co.,LTD_specification/price/image

Product Detail
Company Profile

Model SC-5A
Technique index:
Temp.Range:~95℃
Temp.Fluctuating Range ± 0.1℃
Working Groove Dimen.240 × 150 × 150mm
Working Groove Opening Dimen ф 120
Tank Dept(mm):150
Circulating pump flow(L/Min):No
Total Power(KW):0.65

Model SC-15
Technique index:
Temp.Range:~100℃
Temp.Fluctuating Range ± 0.05℃
Working Groove Dimen.300 × 250 × 200mm
Working Groove Opening Dimen :235*160
Tank Dept(mm):200
Circulating pump flow(L/Min):4
Total Power(KW):2.0

Model SC-15A
Technique index:
Temp.Range:~200℃
Temp.Fluctuating Range :water± 0.1 oil±0.2℃
Working Groove Dimen.300 × 250 × 200mm
Working Groove Opening Dimen :235*160
Tank Dept(mm):200
Circulating pump flow(L/Min):no
Total Power(KW):2.0

Model SC-15B
Technique index:
Temp.Range:~200℃
Temp.Fluctuating Range :water± 0.1 oil±0.2℃
Working Groove Dimen.300 × 250 × 200mm
Working Groove Opening Dimen :235*160
Tank Dept(mm):200
Circulating pump flow(L/Min):4
Total Power(KW):2.0

Model SC-25
Technique index:
Temp.Range:~100℃
Temp.Fluctuating Range :± 0.05℃
Working Groove Dimen.300 × 250 × 300mm
Working Groove Opening Dimen :235*160
Tank Dept(mm):300
Circulating pump flow(L/Min):4
Total Power(KW):2.1

Specifications

1.heating quickly

2. stable temperature

3.easy to operate;

4. Water/Oil dual-use

product description:

High-temperature Circulator or Heating Bath Sink applys to internal or external temperature control, especially fit for external temperature control and measurement, external system could be open or closed. With super power pressure circulating pump, ensure the high-viscosity bath liquid may circulate normally.

Technical Parameters:

Key Features:

1. Microcomputer intelligent control system, heating quickly, stable temperature, easy to operate;

2. Water/Oil dual-use, the maximum temperature : 300C;

3. LED double-windows digital displayer,both showing temperature testing value and setting value; with touch key easy to operate;

4. External circulating pump with the maximum flow rate: 15L/Min, (Now, we can manufacture: 30L/Min);
