High-sensitivity & ultra-high-speed camera utilizes a new generation of backside illumination sensors to enhance the
capture efficiency of incident photons, enabling transient image capture within extremely short exposure times. This is
suitable for ultra-high-speed applications.

Model: NEO 25M/C
Sensor: BSI CMOS
Max Resolution: 1280x1024
Full Frame Rate: 25000fps
Shutter: Global Shutter
Min Exposure Time: 150ns
PIV Cross Frame: 250ns
RAM: 320GB
Support Auto Exposure
Support EDR
Support Record Button
Data Interface: GigE/10GigE
Video Interface: SDI
Input: 3.3/5V TTL
Output: 5V TTL
Time Input Interface: DC IRIG B
Control Interface: RS422 Reserved
Trigger Input: Pulse trigger signal
IO: I Output Interface Reserved, Customizable
NEO 25M/C
Mount: F Port, C/EF Port Options
WxHxD: ≤125x125x210mm
Net Weight: ≤4200g
Thread: 1/4 NPT
Cooling: Fan cooling

High-sensitivity
EDR Secondary Exposure
Intelligent Image Triggering
IRIG-B Synchronization
Flexible Lens Mount
Dual Power Supply
EMC Protection
Flexible for High & Low Temperature Working Environment
Efficient & Easy-to-use Acquisition Software -- RCC
