Accelerated Solvent Extractor ORSE-06
An automated six-channel extraction system for rapid purification of organic compounds from solid and semi-solid samples under elevated temperature and pressure.
Featuring closed-loop extraction, intelligent rack detection, and automatic pressurization, collection, and cleaning, it delivers solvent-efficient, high-throughput sample processing with excellent reproducibility.
Category Insight: Automated solvent extraction systems for high-efficiency organics isolation in environmental, food, forensic, and polymer laboratories.
🔗 Explore related category
Technical Features and Specifications
| Feature |
Details |
| Number of Channels |
Six |
| Pressure Range |
3–150 bar (0.3–15 MPa), independent per channel |
| Temperature Range |
Room temperature–220 °C |
| Flow Accuracy |
≤2% |
| Pressure Accuracy |
≤5 bar (0.5 MPa) |
| Temperature Control Accuracy |
≤2 °C |
| Proportional Valve Channels |
Four |
| Collection Bottle Sizes |
60, 150, 200, 250 mL; customizable |
| Liquid Pump Flow Rate |
1–100 mL/min |
| Extraction Cell Sizes |
10–120 mL (customizable) |
| Dimensions (L×W×H) |
690×535×715 mm |
| Voltage / Frequency |
220 VAC, 50/60 Hz |
| Max Power |
1800 W (10 A) |
| Operating Temperature |
5–45 °C |
| Weight |
85 kg |
Applications: Environmental analysis (PAHs, pesticides, TPH, explosives), food & agriculture (additives, residues, metals), forensics (drug & explosive residues), polymers (plasticizers, monomers), electronics (flame retardants), herbal/medical extracts.
Learn more: Visit ORSE-06 Product Page
