| Product Parameters |
| Sample Block |
6 zones 4x4wellsx0.2ml,6 annealing temp.can be accurately set simultaneously |
| Tube Optional |
0.2ml PCR tube/Strip,96-well PCRplate |
| Heating＆Cooling Technology |
New generation Peltier technology allow 1,000,000 cycles |
| Display |
7’’Color Touch Screen, real-time graphical display |
| Language |
English |
| USB flash drive Function |
Unlimited storage of protocols with USB flash drive |
| Communication Ports |
2 USB &1 LAN |
| Venting System |
Front air in ＆back air out, two thermal cyclers can be placed side by side |
| TEMPERATURE |
| Block Temp.Range |
0℃－105℃ |
| Max.Heating Rate |
5.5℃/S |
| Max.Cooling Rate |
4.5℃/S |
| Temp. Uniformity |
≤±0.15℃(at90℃) |
| Temp. Accuracy |
≤±0.1℃(at90℃) |
| Display Resolution |
0.1℃ |
| Ramping Rate Adjustable |
0.1－4℃/S |
| GRADIENT |
| Gradient Accuracy |
≤±0.15℃(at90℃) |
| 16 Wells Uniformity |
≤±0.2℃(at90℃) |
| Gradient Range |
0℃－105℃ |
| Temp.Differential Range |
0.1-25℃ between two adjacent zones |
| Gradient Capability |
Six temperatures can be set independently, better than traditional gradient function |
| HEAT LID |
| Height Of Heat Lid |
Steplessly adjustable lid, accommodates PCR tubes, strips ＆plates |
| Lid Feature |
Innovative“TOP-OPEN“technology,protection from over-pressure |
| Heat Lid Temp.Range |
30℃－112℃ |
| Auto Shut-off |
Lid will shut off automatically when the block Temp. falls below set Temp |
| SOFTWARE |
| Max.Number Of Programs |
Max.15, 000 programs onboard, unlimited storage of protocols with USB flash drive |
| Max.Step |
30 Steps, multiple nesting cycles available |
| Max.Cycle |
100 Typical Cycles, max 10,000 nesting cycles |
| Time.Increment/decrement |
1-600 sec, available for Long PCR |
| Temp.Increment/decrement |
0.1-10℃, available for Touchdown PCR |
| Auto Pause/ Auto Restart |
Yes |
| Multi-user Log In |
With Password-based authentication to protect personal protocols |
| Tm Calculator |
Automatically calculates the melting ＆annealing Temp.of a pair of primers |
| Hold At4℃ |
A below ambient temp. incubation allow PCR products storage overnight |
| Running Report |
Provide detailed reports of previously run protocols |
| PC Connection |
Remote PC control to manage multiple units across the LAN network |
| OTHER FEATURES |
| Consumption |
600w |
| Dimensions(L×W×H) |
362×256×255mm |
| Net Weight |
7.3KG |
