Electrochemical Autoclave Reactor
Electrochemical Autoclave Reactor
Place of Origin:
China
Brand:
TKA
Model:
WGGDF-100ml
Supplier:
XI'AN MOGINA INSTRUMENT MANUFACTURING CO.,LTD
Price:
Hits:
142
Updated:
8/9/2024
Related Products | Other Products | Related Suppliers
  • Product Detail
  • Company Profile

    Detail

    When this product is used for chemical, chemical high-pressure synthesis or catalytic reaction, it is necessary to measure the temperature, measure the rotational speed, add inert gas, stabilize the pressure and realize the required experimental environment such as online sampling.

    Technical Highlights

    1. The entire reaction process can be observed during the reaction.
    2. The observation window adopts JGS2 high transmittance quartz glass to realize online photochemical reaction under high pressure.

    Application example

    It is suitable for photochemical high pressure reaction, carbon dioxide CO2 reduction, carbon dioxide CO2 reduction to methanol
    Reduction of carbon dioxide CO2 to methane CH4, reduction and degradation of nitrogen oxides NOx, high-pressure photocatalytic degradation of formaldehyde solution, etc. Photocatalytic reaction, Fischer-Tropsch reaction, hydrogenation reaction, polymerization reaction, homogeneous reaction and carbon dioxide supercritical reaction, etc.

    Model Specification

    PN Size Volume Connecion Model Pore diameter Intelligent safety valve Display Accuracy
    WGHX-25ML Φ40*60 25ml Screw Thread 30mm Yes ±1ºC
    WGHX-50ML Φ60*80 50ml Flange 40mm Yes ±1ºC
    WGHX-100L Φ80*120 100ml Flange 40mm Yes ±1ºC
    WGHX-200ML Φ80*140 200ml Flange 60mm Yes ±1ºC
    WGHX-500ML Φ100*240 500ml Flange 60mm Yes ±1ºC

    Products Paraeter

    Volume 25ml,50ml,100ml,200ml,500ml,Can be costomized
    Reactor Material Stainless steel 316L/Titanium/Hastelloy (optional)
    Operating pressure 10MPa/20MPA(optional)
    Valve and Connecting material Stainless steel SU316L
    Reactor liner container: Teflon inner sleeve easy to clean
    Transparent window material: Using polished JGS2 quartz glass (pressure window) or sapphire mirror
    Operating temperature The Max tem.p is 350ºC for Titanium/Hastelloy (optional),The Max tem.p is 250ºC for stainless steel.The tem.p display accuracy is ±1ºC.
    Max pressure/Min Pressure 10Mpa/1Pa
    mixing speed 0-1500RPM
    Speed Accuracy ±5RPM
    Power Supply 220V,50HZ,
    The valve fittings are of European standard, and the interfaces are all standard configuration. The ball valve can be connected with the bottle filled with inert gas to carry out the inert protection experiment reaction, so that the reactant is not in direct contact with the air.
