The stereotaxic instrument, also known as the stereotaxic apparatus, is a three-degree coordinate system specified by landmarks or other reference points outside the skull to determine the location of certain neural structures in the subcortical area for directional stimulation, destruction, injection of drugs, guided potentials, and other investigations under nondirect visual exposure.

It uses some anatomical marks on the surface of the animal skull, such as the sagittal suture, the central axis of the external auditory canal, the central part of the inferior orbital margin, the center of the anterior chimney (bregma), the tip of the herringbone suture (lamda) and the root of the upper teeth, to determine the location of each structure in the deep brain from the outside.

Features：

1. The parallel orbit large animal stereotaxic has all the functions of the standard stereotaxic (such as three- dimensional positioning), which is suitable for the brain scientific research of most large animals;

2. Different animal adapters can be selected, which is suitable for most large animals such as dogs, monkeys, cats and rabbits;

3. The parallel track frame has very good performance and flexibility, and can be fixed on the base plate or directly to the experimental table;

4. The uniquely designed adapter chute is convenient for fixing the head of large animals of different weights;

5. The unique rotating fixed support structure is adopted, and the track can rotate 360 degrees, which is suitable for applications at various angles

6. Two parallel tracks can easily install up to six manipulator arms and perform multiple independent operations on an animal at the same time;

7. Track range：200mm（+100mm～-100mm），Accuracy: 0.1mm;

8. With the use of standard two-dimensional manipulator arm, it can rotate 180 degrees vertically and 360 degrees horizontally;

9. The upper and lower, left and right of the manipulator arm and parallel track adopt vernier caliper reading mode, and the movement accuracy is 100um;

10. Different adapters can be selected (dog, monkey adapter / cat, rabbit adapter);

11. It can be equipped with four manipulator arms.

Model：

Manufacturer: Shanghai Yuyan Instruments Co, Ltd.

Country of Origin:China
