| Model |
OLBM-Z18B |
OLBM-Z23B |
| Capacity |
18L |
23L |
| Sterilization Class |
Class B |
| Sterilization Temp. |
121℃/134℃ |
| Special Program |
HIV, HBV long-sterilization program |
| Drying System |
Vacuum drying system |
| Display |
LCD display |
| Control Precision |
Temperature: 1℃ |
| Pressure: 0.1bar |
| Sterilization Data Output |
Optional Mini printer |
| Standard USB port |
| Safety System |
Pressure lock system |
| Relief valve in case of over pressure |
| Pressure or temperature over load protection |
| Alarm for system failure, finish reminding, water level warning |
| Water Supply System |
Build-in water tank, easy to clean |
| Water Tank Capacity |
3.5L |
| Tray Holder |
3 pcs SS trays on SS shelf |
| Chamber |
Medical stainless steel 304 unibody structure |
| Ambient Temp. |
5~40℃ |
| Noise |
≤65dB |
| Power Supply |
110/220V±10%, 60/50Hz |
| Power Consumption |
2000W |
2000W |
| Chamber Size(mm) |
φ247*360 |
φ247*470 |
| External Size(mm) |
600*495*410 |
700*495*410 |
| Packing Size(mm) |
810*610*590 |
810*610*590 |
| Gross Weight(kg) |
63 |
65 |
