Integrative Design All Steel Standard Type Laboratory Fume Hood
Fume hood is one kind of lab furniture, essential for laboratory, which plays the role of exhaust and ventilation. It is one of the most commonly used local exhaust equipment in the laboratory.
The structure of standard Type fume hood is upper-lower type, there is an exhaust hole at the top, which can be installed with vent blower.
The upper cabinet has lining baffles, controller, lamp, sockets, etc.
and the visible window adopts tempered glass, can be moved up-down, freely operated by the personnel.
The lower cabinet is wall bench type, the upper is worktop, can be installed with water sink&tap. the lower is cabinet body.
- The outer layer is steel shell, with 1.0mm thick galvanized steel plate stamped and bent into one piece, the surface is coated by electrostatic spraying epoxy resin powder, acid and alkali resistance, corrosion resistance, the adhesive force of its spraying epoxy resin protective coating is good after the test of drop impact;
- The inner layer is lining baffles, use 5-6 mm thick compact laminate (compact chemical base board) to make, including top baffle, side baffle, back baffle, guide baffle, coated by electrostatic spraying epoxy resin powder, have excellent effects for moisture resistance, bending resistance and impact resistance;
1. The guide baffles adopt 3-section exhaust design, can eliminate the exhaust dead corners and contribute to discharge gases with different densities; also keep the fume hood section face velocity at about 0.5m/s (100fpm).
2. It adopts side (T01) or back(T02) counterweight structure and knock-down movable baffles(with maintenance window), which is convenient for maintenance and upgrade of counterweight, water, electricity and gas.
- Sliding Window System
1. Visible window: ≥5mm thick anti-explosion tempered glass, slides smoothly, can stop at any position of the track, which is convenient to operate; the max opening height is not more than 750mm.
2. Steel-wire Rope drive or Belt drive counterweight
3. Metal window frame and alum-alloy bow type handle or PP integrative handle
- Electrical System
1. Controller= LCD screen intelligent control panel: the controller is set on one side of outer column, is convenient for observation and operation.
2. Socket: use 10A/16A 220V multifunctional sockets with dust-spray proof protecting cover. The outer size is 60*60mm, suitable for all kinds of lab equipment.
3. Lighting: use integrative LED lamp, hidden in the top baffle, will not be in touch with the gases of the fume hood, easy to be changed, the luminance is enough for experiment purpose.
4. Equipped with overload and short circuit protection safety device.(T02 only)
Lower Cabinet:
- Worktop: generally use 12.7mm thick solid core physicochemical board, acid and alkali resistant, corrosion resistance.
Optional: epoxy resin board, ceramic board, marble or stainless steel sheet.
- Cabinet body(frame, door, drawer): overall assembly structure, made of 1.0mm thick galvanized steel plate with surface coated by epoxy resin powder.
1. Hinge: use damping hinges, with opening angle is 90° or 115° or 175°, can be closed automatically without noise, no spring back, high strength and can not easily be broken, open-close can reach over 50,000 times.
2. Handle: use embedded type or U type alum-alloy handles or integrative type bent steel handles, strong solid and elegant appearance.
|
Name |
Dimension |
Model |
|
Standard Type Fume Hood |
1200*850*2350mm 1500*850*2350mm 1800*850*2350mm |
XC-FH1200 XC-FH1500 XC-FH1800 |
NOTES:
1 We can design and manufacture non-standard dimension as per user's requirements.
2.The price excluding vent blower, vent pipe& elbow, water sink&tap, flow control valve, cock.
Optional Accessories
water sink, water faucet, piping(vent pipe and elbow), vent fan, cock&valve, etc
Packaging&Shipping
Because the weigh and dimension are big, generally the lab benches, fume hoods or lab cabinets will be shipped by Sea;
They would be packed in carton (FCL sea shipping) or plywood box with pallet(LCL sea shipping) in assembled or disassembled state.
While Air shipping is available if you accept the shipping cost!
Application
biological pharmacy, biological analysis, plant culture, environmental test, electronic instruments and scientific research, etc.
Project Cases
Porject 1 Desription:
6 laboratory fume hoods 1200*850*2350mm for local school use (from Zimbabwe feedback)
Project 2 Description:
The 13 fume hoods for Zambia petroleum(refine oil)laboratory, which were installed, and work well now
Customer Visit
Zambia Customer Visit
The Zambia customer only 1 guy, who ordered 13 fume hoods 1600*850*2350mm, and another 40 ones are under discussion, just wait for the goverment prodecure, will be confirmed soon.
We have further discussion for future cooperation like warehouse for our lab furniture, and they company will pay a visit again next year.
Zimbabwe Customer Visit
who ordered six lab fume hoods 1200*850*2350mm (also 2 emergency shower eye washes and 40 water taps)as trial order, they came to check the goods before shipping.
The coming sample order: island bench 3000*1500*850mm and wall bench 1500*750*850mm &wall cabinet 1500*350*600mm intended for their showing room.
And we both hope to extend our products to Zimbabwe and countries nearby, and the sole distribution agreement under discussion.
Company Profile
Xuecheng Global Trader Co., Ltd is one professional industry and trade company for lab furniture, integrating production, R&D, sales, installation and after-sale service, located in beautiful Olympic Sailing City- Qingdao, China.
After years' development, we have grown into one diversified company, engaged in lab furniture&lab equipment, school furniture&school supplies, medical furniture&medical equipment, etc
- Workshop& Production Line
- Certificate
xuecheng-globe.com
xuecheng-globe.net
facebook.com/xuechenglab
instagram.com/xuechenglab
-
Xuecheng Global Trader Co., Ltd/ Jimo(Qingdao) Xuechengli Furniture Ltd
founded in 2010, located in beautiful Olympic sailing city- Qingdao, is one professional manufacturer for lab furniture, integrating production, R&D, sales, installation and after-sale service.
Xuechenglab got SGS and CE certification, we have professional R&D, production team, excellent after-sales support and rich market development experience.
After years' development, we have grown into one diversified business company, involved in laboratory furniture, laboratory equipment, medical equipment, and we can provide one-stop solutions to the users with laboratory ventilation system, laboratory air cleaning system, laboratory gas supply system, etc
Our products are widely used in medicine, chemical industry, commodity inspection, quality inspection, environmental protection, food and beverage, electronics, universities, hospitals, scientific research institutions and other industries.
We have successfully exported our products to approx 40 countries and regions, including Australia, New Zealand, USA, Canada, Africa, Latin America, Middle East and European Union.
We have been committed to providing overall solutions for the laboratory and medical industry, and we are also striving to become the optimal partner to customers all over the world.
Strive to do every detail well to provide high-quality products and services to you!
