Product Features
The shell is made of cold-rolling steel with static spray plastics, the working chamber is made of mirror stainless steel, the shelves can be adjusted at will;
Microcomputer control system with temperature and time control and over-temperature alarm;
Preheating chamber design, the air directly into the chamber after heating and mixing, to ensure rapid heating and good heat distribution effect;
Dual LED screens and touch keys;
Shaded pole motor and wind blade, with air convection breeze device, the air in the chamber can be renewed and circulated;
Observation window on the door, convenient for users to observe;
The rotary two-stage locking structure has good sealing performance;
Four rounded corners of the chamber, the shelves are easy to disassemble and clean;
Power supply recovery function, data will not be lost when power failure and system halted.
Technical Parameters
Model
GZX-9023MBE
GZX-9030MBE
GZX-9070MBE
GZX-9140MBE
GZX-9240MBE
GZX-9420MBE
Volume [L]
20
40
76
142
234
456
Temp. Range [°C]
RT+5~200
RT+5~200
RT+5~200
RT+5~200
RT+5~200
RT+5~200
Temp. Resolution [°C]
1
1
1
1
1
1
Temp. Fluctuation at 105°C [°C]
±1
±1
±1
±1
±1
±1
Temp. Uniformity [%]
±2.5
±2.5
±2.5
±2.5
±2.5
±2.5
Heating Rate to 180°C [°C/min]
˃4
˃4
˃4
˃4
˃4
˃4
Power [W]
750
950
1350
1750
2150
3100
Power Supply [V, Hz]
220±10%, 50±2%
220±10%, 50±2%
220±10%, 50±2%
220±10%, 50±2%
220±10%, 50±2%
380, 50
Timer Range [min]
0~999
0~999
0~999
0~999
0~999
0~999
Internal Dimensions W×D×H [mm]
300×335×275
350×330×350
450×380×450
550×470×550
600×520×750
638×586×1348
Housing Dimensions W×D×H [mm]
568×447×452
640×556×505
740×606×605
840×696×705
890×746×905
780×696×1760
Number of Shelves (std./max.) [pc]
2 / 3
2 / 4
2 / 5
3 / 7
3 / 10
3 / 6
Load per Shelf [kg]
15
15
15
15
15
15
