Boom Stand Stereo Zoom Microscope: XTW7045 series
Description:
XTW7045series offers our best value boom stereo microscope . It includes the upgraded and popular 0.7X-4.5X zoom stereo microscope head,extra wide viewing field, large zoom ratio and long working distance, wide scale of optional accessoreis to meet different demand. this boom stand microscope is for larger applications and can be mounted to the floor and have an added boom to act as a counterweight. These stands are used for commercial inspection applications such as soldering, circuit board inspection and repair and engraving. Expand the scope of operations, any orientation and angle observed the objectives
XTW7045B1 XTW7045B2
| XTW7045 series | Standard Specification | A1 | B1 |
| Viewing Head | Binocular head , Inclined at 45° ,360°rotatable, interpupiillary distance : 55-75mm, both ocular-tube with diopter adjustment +/-5°, |
√ | √ |
| Eyepiece | Wide Field Eyepiece WF10X/20, with Eyepiece guard | √ | √ |
| WF15X, WF20X | √ | √ | |
| Objective | Zoom objective:0.7X-4.5X | √ | √ |
| Auxiliary Lens | 0.5X, 1.5X, 2X | O | O |
| Zoom ratio | 1:6.4 | √ | √ |
| Vertical Pillar Height | 380mm | √ | √ |
| Base/working stage | Square base size: 230x230x40mm | √ | |
| Square base size:210x260x40mm | √ | ||
| Working distance | 100mm | √ | √ |
| Arm | Single Arm | √ | |
| Double Arm | √ | ||
| Horizontal Moving range | 235mm | √ | √ |
| Light source | Natural Light | √ | √ |
| Optional Accessories | High resolution digital camera: 1.3MP, 3.0MP, 5.0MP with software | O | O |
| Super Light annular LED Light Lamp | O | O | |
| Annular fluorescent lamp: 8W, 10W | O | O |
Note:"√" standard outfit,"o" optional
Optical Data:
| Eyepiece | Standard Specifications | Auxiliary 0.5X | Auxiliary 1.5X | Auxiliary 2X | ||||
| Working Distance:100mm | Working Distance:165mm | Working Distance:45mm | Working Distance:30mm | |||||
| Magnification | Viewing Field | Magnification | Viewing Field | Magnification | Viewing Field | Magnification | Viewing Field | |
| WF10X/20 | 7.0X | 28.6mm | 3.5X | 57.1mm | 10.5X | 19mm | 14X | 14.3mm |
| 45X | 4.4mm | 22.5X | 8.9mm | 67.5X | 3mm | 90X | 2.2mm | |
| WF15X/15 | 10.5X | 21.1mm | 5.25X | 42.8mm | 15.75X | 14.3mm | 21X | 10.7mm |
| 67.5X | 3.3mm | 33.75X | 6.7mm | 101.25X | 2.2mm | 135X | 1.7mm | |
| WF20X/10 | 14.0X | 14.3mm | 7.0X | 28.6mm | 21.0X | 9.5mm | 28X | 7.1mm |
| 90.0X | 2.2mm | 45.0X | 4.4mm | 135.0X | 1.5mm | 180X | 1.1mm | |
Optional Parts:
-
