- 100M2 Food Lyophilizer
- Product Detail
- Company Profile
Equipment Performance
Model:FZG-100-ra
Equipment size (L*W*H):8970*2660*3200
Power supply:3P / 380V / 50HZ
Machine structure:Chamber and cold trap are integral front and rear structure; The unit is an independent unit
Area of plates:100.32m2
Input capacity:1000Kg
Maximum ice capacity:1500Kg
Shelf stack:(18+1 )*2(upper radiant shelf), shelf spacing 74 mm
Maximum temperature of the plate :100℃
Cooling rate of cold trap:30~-40℃≤30min
Lowest temperature of cold trap:-65℃
Pressure of chamber≤10Pa
Vacuumizing rate:1atm~133Pa≤15min
-
Shanghai Leewen Scientific Instrument Co.,Ltd. is one of leading professional manufacturing enterprises of low-temperature laboratory equipment and ultrasonic equipment, Photochemical products and other lab testing machine in china.
Our company’s main products are grouped in 6 series:
Photocatalytic Reactors
Spray Dryer| Freeze Dryer
Ultrasonic Instruments
Low Temperature Water Bath
Shaker|Oscillator
Lab General Instruments
Through all our staffs joint efforts ,our main products are exported to Southeast Asia, The Middle East, Africa, Europe and The United states, and other countries and regions, now we are looking forward to cooperating with you and create a new future together.
