EDR-700A 96 well Micro plate dispenser

【Characteristic】
a)    CV≦±1%
b)    Liquid transfer volume 1μL-20μL/10μL-300μL （1μL-20μL Optional）
c)    Process speed 14sec./plate（@100μL）
d)    96ch liquid head Dispense, suck in speed and dispense speed can be adjusted（10μL-400μL/sec）
e)    (Maximum 20)plates hopper（can add plates on any time on the process）

【Specifications】

TYPE	EDR-700A
Ambient	10 ～ +50℃（None Dewfall），humidity less than 85%
Dispense	1μL～20μL/10μL～300μL (1μL～20μL Optional)
Dispense Mode	96ch Independent cylinder
Plates	96ch micro plate
process speed	14sec./plate（@100μL Contact dispense）
Liquid Suck/Dispense speed	Adjustable （10～400μL/sec.）
Liquid head	96ch metal nozzle/96ch tip nozzle（need tip loading unit，optional）
Precision	CV<=1%（@100μL Dispense）
Micro plate hopper feeder	20plates supply and 20plates collect hopper （can add plates on any time on the process）
Dimension	490（W）×450（D）×354mm（H）
Weight	30Kg
Power	AC100V(AC220 available)，150VA

【Optional Unit】

Name	Price
Mixing unit
Stirrer unit
Acrylic reagent container
PP reagent container
Acrylic reagent container for stirrer unit
PP reagent container for stirrer unit
Liquid container sensor unit
tip loading unit
