Heated Multi Position Hotplate Magnetic Stirrer
Heated Multi Position Hotplate Magnetic Stirrer
Place of Origin:
China
Brand:
LEEWEN
Model:
ZR-D4/ZR-D6
Price:
Hits:
2291
Updated:
4/30/2025
  • Product Detail
  • Company Profile



    Heated Multi Position Hotplate​ Magnetic Stirrer



    4 or 6-plate heated stirrer.

    Individual heat and stirring speed control.

    Digital control with high-performance microprocessor

    Ceramic panel, resistant to strong acid, strong alkali and other corrosive solutions

    Optional PT100 temperature sensor to accurately control sample temperature

    Model

    ZR-D4

    ZR-D6

    Number of stirring points

    2×2 points

    3×2 points

    Stirring capacity(H2O)

    5L/point

    5L/point

    Motor input power

    15W×4

    15W×6

    Speed range

    10~2000rpm

    10~2000rpm

    Temperature control range

    RT+5~280℃

    RT+5~280℃

    Temperature control accuracy

    ±0.5℃

    ±0.5℃

    Temperature resolution

    0.1℃

    0.1℃

    Heating output power

    350W/Point, total 1400W

    350W/Point, total 2100W

    Max length of stir bar

    60mm

    60mm

    Display

    LCD

    LCD

    Timing

    0~99H59M or continuously

    0~99H59M or continuously

    Working plate size

    Φ135mm

    Φ135mm

    Material

    Panel: Matt Teflon Panel,resistant to strong acids and alkalis and other corrosive liquids

    Body: Anti-rust coated steel plate

    Power supply

    AC220V, 50/60Hz

    Dimensions(W*D*H)

    510*240*100mm3

    510*410*180mm3

    N.Weight

    10kg

    18kg

    Packing Size

    540*330*170mm3

    570*540*230mm3

    G.Weight

    15kg

    23kg
