Heated Multi Position Hotplate Magnetic Stirrer
4 or 6-plate heated stirrer.
Individual heat and stirring speed control.
Digital control with high-performance microprocessor
Ceramic panel, resistant to strong acid, strong alkali and other corrosive solutions
Optional PT100 temperature sensor to accurately control sample temperature
|
Model
|
ZR-D4
|
ZR-D6
|
|
Number of stirring points
|
2×2 points
|
3×2 points
|
|
Stirring capacity(H2O)
|
5L/point
|
5L/point
|
|
Motor input power
|
15W×4
|
15W×6
|
|
Speed range
|
10~2000rpm
|
10~2000rpm
|
|
Temperature control range
|
RT+5~280℃
|
RT+5~280℃
|
|
Temperature control accuracy
|
±0.5℃
|
±0.5℃
|
|
Temperature resolution
|
0.1℃
|
0.1℃
|
|
Heating output power
|
350W/Point, total 1400W
|
350W/Point, total 2100W
|
|
Max length of stir bar
|
60mm
|
60mm
|
|
Display
|
LCD
|
LCD
|
|
Timing
|
0~99H59M or continuously
|
0~99H59M or continuously
|
|
Working plate size
|
Φ135mm
|
Φ135mm
|
|
Material
|
Panel: Matt Teflon Panel,resistant to strong acids and alkalis and other corrosive liquids
Body: Anti-rust coated steel plate
|
|
Power supply
|
AC220V, 50/60Hz
|
|
Dimensions(W*D*H)
|
510*240*100mm3
|
510*410*180mm3
|
|
N.Weight
|
10kg
|
18kg
|
|
Packing Size
|
540*330*170mm3
|
570*540*230mm3
|
|
G.Weight
|
15kg
|
23kg
|
