Description:

ZXDP-B series direct heating incubators offer an economical incubation method to a variety of micro-organism cultures. As a standard feature, all incubators have a high-tech microprocessor controller that maintains accurate temperature control (PID) of the chamber in the range of ambient +5°C to 65°C. With an accuracy of ±0.1°C, a user-friendly sealed control panel allows easy digital setting and fast readout of time and temperature as well as an alarm signal if there is a deviation from set point parameters. The processor of our incubators can store up to 9 programs-18 steps-into a “non-volatile” memory. Programs can be used for running multiple "ramp and soak" cycles up to 99 times. Of course the incubators can also be used as a constant (one) temperature incubator.

Features:

P.I.D. microprocessor ensures the precision of temperature control under both fixed value mode and program mode.
Fully programmable through the keyboard (9 programs/18 steps).
Forced-air circulation provides uniformity of ±0.5°C@37°C
Audible and visible alarm on over temperature.
Password protection against unauthorized access to all settings.
Non-volatile memory retains preset parameters after an accidental power interruption.
Large LCD display for easy parameters setting and fast readout.
Inner glass door provides complete visibility to the chamber.

Specifications：

Model	ZXDP-B2050	ZXDP-B2080	ZXDP- B2120	ZXDP-B2160	ZXDP-B2270
Heat Mode	Direct Heat (With Gentle Circulation)
Volume (L)	50	80	120	160	270
Temperature Range	Ambient+ 5 to 65°C
Temperature Accuracy	± 0.1°C
Temperature Uniformity	±0.5°C@37°C
Alarm	Enabled
Timer	1-999 minutes
Setting	Digital
Display	LCD
Grid Included	2 (max 4)	2 (max 4)	2 (max 5)	2 (max 4)	2 (max 4)
Grid Size(mm) (WxD)	330x345	380x395	430x445	480x495	530x595
Distance Between Grids (mm)	80	100	110	130	160
Inner Dimensions (mm) (WxDxH)	350x350x410	400x400x500	450x450x600	500x500x650	600x550x820
Exterior Dimensions (mm) (WxDxH)	470x465x760	520x515x850	570x565x950	620x615x1000	720x665x1170
Packing Dimensions (mm) (WxDxH)	590x590x930	640x640x1020	690x690x1120	740x740x1170	840x840x1340
Net Weight (kg)	33/57	40/73	51/85	57/94	90/130
Power (W)	200	250	300	380	550
Electricity	220-240V AC 50/60 Hz
Approval	CE, ISO

Order Information:

ZXDP-B2050	ZXDP-B2050,50L, Direct Heat Incubator, A+5-65℃	P9001	Grid Plate for ZXDP-B2050, S/S
ZXDP-B2080	ZXDP-B2080,80L, Direct Heat Incubator, A+5-65℃	P9002	Grid Plate for ZXDP-B2080, S/S
ZXDP-B2120	ZXDP-B2120,120L, Direct Heat Incubator, A+5-65℃	P9003	Grid Plate for ZXDP-B2120, S/S
ZXDP-B2160	ZXDP-B2160,160L, Direct Heat Incubator, A+5-65℃	P9004	Grid Plate for ZXDP-B2160, S/S
ZXDP-B2270	ZXDP-B2270,270L, Direct Heat Incubator, A+5-65℃	P9005	Grid Plate for ZXDP-B2270, S/S
※ S/S: Stainless Steel
