ZXSD-R1160 160L, Premium Cooled BOD Incubator
ZXSD-R1160 160L, Premium Cooled BOD Incubator
Place of Origin:
China
Brand:
Shanghai ZHICHENG Analytical Instrument Manufacturing Co.,Ltd
Model:
ZXSD-R1160
Price:
Hits:
5914
Updated:
12/3/2022
  • Product Detail
  • Company Profile

    Description:

    The premium BOD incubators of the ZXSD-R series from LABWIT are designed to meet a variety of advanced experimental needs, ranging from BOD determination to incubation of micro-organism cultures, preservation of samples, Drosophila incubation and determination of enzymatic activities. It features a 4.3'' TFT touch screen panel, which ensures clear indication as well as easy operations. Each of the four models has a wide temperature range from ambient -18 °C (minimum 4°C) to 65 °C and can be operated at a single user defined temperature, but can also be programmed with up to 9 different temperature segments within a time frame (18 steps). The (cooling) compressor runs continuously and the control is done through a solenoid valve for more precise temperature control if lower than ambient temperatures are required.

    ZXSD-R series BOD incubators also feature a back-up program in case of power failures, the stored parameters remain in the memory of the microprocessor. Your experiment therefore resumes under the same conditions even when interrupted by an interruption of power.



    Features:

    • P.I.D. microprocessor ensures the precision of temperature control under both fixed value mode and program mode.
    • 4.3'' TFT touch screen panel displays all parameters, easy operation and readout for all control modes.
    • Three-dimensional heating system ensures fast response, and high uniformity of ±1.0°C@37°C.
    • Sound cooling system with CFC free refrigerant and automatic defrosting system.
    • Real-time electronic timer from 0 to 999 minutes.
    • Alarms for sensor failure, high and low temperature and power cut.
    • Password protection of all parameters against unauthorized access.
    • Non-volatile memory retains pre-set parameters in case of power interruption.
    • Triple safety protections for samples, incubator and environment.
    • Independent device for over temperature, high current flow and electric leakage.
    • Standard configurations; a double layer tempered glass observe window in outer door, an inner glass door, forced air circulation, a fluorescent lamp, 50 mm test port and 2 grids, built-in printer.
    • Optional UV Lamp, RS-232 interface available.



    Specifications:



    Model

    ZXSD-R1090

    ZXSD-R1160

    ZXSD-R1270

    ZXSD-R1430

    Volume (L)

    90

    160

    270

    430

    Door Type

    Outer door with observation window, and heat resistance glass inner door

    Temperature Range (°C)

    4 to 65

    Temperature Accuracy  (°C)

    0.1

    Temperature Uniformity  (°C)

    ±1.0 @37℃

    Alarm

    Enabled

    Timer (min)

    0-9999

    Settings

    Digital

    Display

    4.3'' TFT Touch Screen

    Grids Included

    2 (Max 11)

    2 (Max 15)

    2 (Max 18)

    2 (Max 25)

    Grid Size (mm) (WxD)

    310x356

    410x456

    513x556

    555x656

    Inner Dimensions (mm) (WxDxH)

    400x400x500

    500x500x650

    600x600x750

    700x645x950

    Exterior Dimensions (mm) (WxDxH)

    530x540x1260

    630x640x1360

    730X740X1460

    830X785X1660

    Packing Dimensions (mm) (WxDxH)

    650X660X1430

    750X760X1530

    850X860X1630

    950X905X1830

    Net/Gross Weight (kg)

    68/108

    98/145

    130/180

    180/220

    Power (W)

    710

    860

    950

    1350

    Electricity

    220-240V 50/60 Hz

    Approval

    CE, ISO









    Order Information:

    ZXSD-R1090

    ZXSD-R1090, 90L, Pre Cooled BOD Incubator, 4-65℃

    ZXSD-R1160

    ZXSD-R1160,160L, Pre Cooled BOD Incubator, 4-65℃

    ZXSD-R1270

    ZXSD-R1270,270L, Pre Cooled BOD Incubator, 4-65℃

    ZXSD-R1430

    ZXSD-R1430,430L, Pre Cooled BOD Incubator, 4-65℃

    P9010

    Grid Plate for ZXSD-R1090, S/S

    P9011

    Grid Plate for ZXSD-R1160, S/S

    P9012

    Grid Plate for ZXSD-R1270, S/S

    P9013

    Grid Plate for ZXSD-R1430, S/S

     S/SStainless Steel
