ZWFR-200 69L Premium Reciprocal Shaking Incubator, Cooled
ZWFR-200 69L Premium Reciprocal Shaking Incubator, Cooled
Place of Origin:
China
Brand:
Shanghai ZHICHENG Analytical Instrument Manufacturing Co.,Ltd
Model:
ZWFR-200
Price:
Hits:
4480
Updated:
11/2/2024
  • Product Detail
  • Company Profile

    Descriptions:

    This new premium benchtop shaking incubators provided by LABWIT offer conditions of time, temperature and orbital or reciprocal agitation for the growth of biological organisms. This microprocessor controlled shakers have a number of advanced features that are really unique in bench top models.

    This unique benchtop model with shaking diameter stepless adjustable from 1-50mm provides unmatched flexibility for meeting comprehensive application requirements. As one of the new features, the sophisticated PID controller provides these units with choices of not only constant controlling one fixed temperature and speed, but also programmed controlling with a series of “ramps and soaks” segments. Moreover, together with the introduction of large TFT touch screen, this unique unit can assist you finish all complicated program settings just with finger tips.

    For data recording, the units are equipped with a built-in thermo printer as standard, so that operators could check how the performance parameters vary according to specified process without having to be on site.



    Features:

    • 4.3'' LCD 480x272 touch screen panel clearly indicates all parameters in one page display.
    • Unit can be programmed to operate with 9 segments for temperature and shaking speed.
    • Chamber & tray from electro polished stainless steel.
    • Special low noise induction motor system enables high reciprocating speed up to 240rpm.
    • Single counter balanced drive allows stroke continuous adjustment from 1 to 50 mm.
    • AC inductive motor, brushless and maintenance free.
    • Password protection against unauthorized change of parameters.
    • Audible and visual alarms on over temperature and motor overheating, and automatically cut off the power.
    • Soft start and smooth acceleration when lid is closed after short opens.
    • Timer up to 9999 mins under fixed value control mode.
    • Predrilled standard tray included, without clamps.























    Specifications:



    Model

    ZWYR-200D

    ZWYR-240

    ZWFR-200

    Control

    P.I.D Microprocessor

    Control Mode

    Fix Value or Program (up to 9 Segments)

    Control Panel

    4.3''LCD Touch Screen

    Volume (L)

    69

    Shaking Speed (rpm)

    30-600

    30-400

    30-240

    Stroke (mm)

    1-50 Stepless Adjustment

    Shaking Mode

    Orbital

    Reciprocal

    Tray (mm) (WxD)

    400x370

    435x420

    Ambient Temperature(ºC)

    5-25

    Temperature Range (ºC)

    4-60

    Temperature Accuracy (ºC)

    0.1

    Temperature Uniformity (ºC)

    ±1ºC@37℃

    Timer

    1 to 9999 mins

    Inner Dimensions (mm) (WxDxH)

    490x450x315

    490x450x335

    490x450x315

    Exterior Dimensions (mm) (WxDxH)

    774x732x605

    Packing Dimensions (mm) (WxDxH)

    895x852x775

    Net/Gross Weight (kg)

    100/132

    Power (W)

    700

    Electricity

    220-240V 50/60 Hz

    Approval

    CE, ISO

    Shortcut Settings

    Control Mode, Constant Temperature, Automatic Cooling Control, Power-off Recovery Switch, Door Switch, Print Switch

    Security

    Over-temperature Protection, Compressor Overload Protection, Electrical Leakage Protection

    Additional

    Built-in Printer, RS485 COM Kit (Option)









    Order Information:





    ZWYR-240

    ZWYR-240, 69L, Pre Orbital Shaking Incubator 4-60, 30-400rpm

    P8003

    T Clamp, S/S, for 250ml Flask, with Spring Retainer

    ZWYR-200D

    ZWYR-200D,69L, Pre Orbital Shaking Incubator 4-60, 30-600rpm

    P8014

    T Clamp, S/S, for 300ml Flask, with Spring Retainer

    ZWFR-200

    ZWFR-200,69L, Pre Reciprocal Shaking Incubator 4-60, 30-600rpm

    P8004

    T Clamp, S/S, for 500ml Flask, with Spring Retainer

    P6004

    Tray for ZWY-240/200D, S/S

    P8005

    T Clamp, S/S, for 750ml Flask, with Spring Retainer

    P7003

    Universal Tray for ZWY-240/200D

    P8006

    T Clamp, S/S, for 1000ml Flask, with Spring Retainer

    P8001

    T Clamp, S/S, for 50ml Flask, with Spring Retainer

    P8010

    Tube Rack S/S

    P8002

    T Clamp, S/S, for 100ml Flask, with Spring Retainer

    P8011

    Tube Rack ABS Plastic

    P8013

    T Clamp, S/S, for 150ml Flask, with Spring Retainer

    P8012

    Clamp for 96 Well Plate, S/S

    S/S: Stainless Steel
