    Product infotmation:

      The Nano-300 is an advanced model of Micro UV VIS Spectrophotometer based on Nano-100, with full range of wavelength (200-800nm). It is with an added new function of bacterium cell concentration measurement (OD600) in a cuvette. The Nano-300 only requires 0.5-2ul sample to measure nucleic acids, protein as quickly like Nano-100 do. Nano-300 come with a 7 inch touch screen and integranted Android operating system, with no computer required. It is an ideal equipment for a biology laboratory to make life science research more efficient.

    Adding sample     Measuring sample    quick and easy cleaning


    1. 7 inch touch screen with simple interface. No computer required

    2. Android operating system with free software update

    3. Only require 0.5-2ul sample to perform accurate measurements.

    4. Long life’s Xenon flash lamp for up to 10 years

    5. Flexible data output. The data can be printed with built-in printer, and output via USB memory stick

    6. OD600 measurement, ideal for bacterial concentration measurement

    7. Direct micro-volume measurement with 0.5-2ul of sample. Eliminates the need for expensive accessories.

    8. Wide range of wavelength (200-800nm)

    9. Turn on and instantly measure without lamp warm up time; Full scan capability from 200-800nm with 6 sec.

    10. Switch off automatically when the machine is idle for more than 5mins, and awake by touching the screen.

    Technical Data

    Model  Nano-300
     Wavelength Range  200~800nm
     Sample Size  0.5~2.0ul
     Path Length  0.2mm (For high concentration measwrement)
     1.0mm (Ordinary concentration)
     Light Source  Xenon flash lamp
     Detector Type  3864-element linear silicon CCD array
     Wavelength Accuracy  1nm
     Spectral Resolution  ≤3nm (FWHM at Hg 546nm)
     Absorbance Precision  0.003Abs
     Absorbance Accuracy  1% (7.332Abs at 260nm)
     Absorbance Range  0.02 - 100A
     Detection Range  10~5000ng/ul (dsDNA)
     Measurement Time  <6s
     Dimensions (W x D x H)mm  210 x 268 x 181
     Data Output  USB, SD-RAM Card
     Weight  2.8kg
     Sample Pedestal Material  Aluminum alloy and Quartz fiber
     Operating Voltage  24VDC
     Operating Power Consumption  40W
     Standby Power Consumption  5W
     Software Compatibility  Android System
     OD600nm Measurement:
     Light Source  LED
     Wavelength Range  600±8nm
     Abosorbance Range  0~4A


    Code                         Description
    AS-11020-00             Nano-300  Micro-Spectrophotometer DC24V  5W

    Hangzhou Allsheng Instruments Co., Ltd. (Allsheng) was established in 2006 and Allsheng is a professional engaged in laboratory instruments, molecular biology instruments and medical equipment for R&D, production, sales and services enterprises. Allsheng company is located in Hangzhou city and employs more than 100 people.

    With strong R&D team and senior management team, Allsheng products win a good reputation from the market. Benefit from its unique design and superior performance, you can easily find Allsheng's products in Europe, U.S.A., Southeast Asia, Korea, Japan, the Middle East, and so on.
