OLIGO oligonucleotide synthesis column
OLIGO oligonucleotide synthesis column
Place of Origin:
China
Brand:
JIZHOUAUTO
Model:
70mm,100mm,140mm,200mm,250mm,350mm
Price:
Hits:
Updated:
12/24/2025
  • Product Detail
  • Company Profile
    OLIGO oligonucleotide synthesis column
    The Oligo stainless steel synthetic column is designed for oligonucleotide synthesis and can withstand the harsh organic conditions involved in oligonucleotide synthesis.
    Product Features
    The height of the column bed can be adjusted, and it is recommended that the working height of the column bed be between 50mm and 300mm
    Can withstand the harsh organic solvent conditions during synthesis
    The synthesis column is easy to operate and the solid-phase carrier packaging is convenient
    The Oligo synthesis column also has specifications suitable for large-scale synthesis, with diameters of 35mm, 50mm, 70mm, 100mm, 140mm, 200mm, 250mm, 270mm, 350mm, 500mm, and other specifications


    Model Selection
    Art.No Product Name inner diameter Loading height Max.Pressure Column material
    JZ-0910 Oligo70L Synthetic Column 70mm 50-300mm 2Mpa SS316L
    JZ-0911 Oligo100L Synthetic Column 100mm 50-300mm 2Mpa SS316L
    JZ-0912 Oligo140L Synthetic Column 140mm 50-300mm 2Mpa SS316L
    JZ-0913 Oligo200L Synthetic Column 200mm 50-300mm 2Mpa SS316L
    JZ-0914 Oligo250L Synthetic Column 250mm 50-300mm 2Mpa SS316L
    JZ-0915 Oligo350L Synthetic Column 350mm 50-300mm 2Mpa SS316L
    JZ-0916 Oligo500L Synthetic Column 500mm 50-300mm 2Mpa SS316L


    Oligo oligonucleotide synthesis column Technical parameters
    (inner diameter: 70/100/140/200 mm)
    Synthesis column Description
    Column material SS 316L
    inner diameter 70/100/140/200 mm
    Loading height 50-300 mm
    Inlet/Out connection 25mmTC
    Maximum work pressure 2MPa
    Material of upper and lower support plates SS 316L
    Gasket material FFKM
    Sieve plate aperture 10µm( optional 20um,5um,2um)
    frame material AISI 316L /AISI 304
    Piston sealing method O-ring
    Polishing of stainless steel
    parts in contact with liquid material
    Ra ≤0.4µm
    support 3 casters and 3 tripod support legs

    Oligo250 oligonucleotide synthesis column Technical parameters
    (inner diameter: 250/270mm)
    synthesis column Description
    Column material SS 316L
    inner diameter 250 mm/270mm
    Loading height 50-300 mm
    Inlet/Out connection 25mmTC
    Maximum work pressure 2MPa
    Material of upper and lower support plates SS 316L
    Gasket material FFKM
    Sieve plate aperture 10µm( optional 20um,5um,2um)
    frame material AISI 316L /AISI 304
    Piston sealing method O-ring
    Polishing of stainless steel
    parts in contact with liquid material
    Ra ≤0.4µm
    support 3 casters and 3 tripod support legs


    Oligo350 oligonucleotide synthesis column Technical parameters
    (inner diameter: 350/500 mm)
    Synthesis column Description
    Column material SS 316L
    inner diameter 350 mm/370mm/500mm
    Loading height 50-300 mm
    Inlet/Out connection 50mmTC
    Maximum work pressure 2MPa
    Material of upper and lower support plates SS 316L
    Gasket material FFKM
    Sieve plate aperture 10µm( optional 20um,5um,2um)
    frame material AISI 316L /AISI 304
    Piston sealing method O-ring
    Polishing of stainless steel
    parts in contact with liquid material
    Ra ≤0.4µm
    support 4 casters and 4 tripod support legs


    Other specifications can be customized according to needs
