The NITRO-GEN+ Nitrogen Generator (Catalog# NA1935) is compatible with all Organomation nitrogen evaporators up to 100 sample positions, and is designed to fulfill the needs of sample preparation and LC-MS analysis. It is a self-contained generator that is able to produce up to 35 LPM of nitrogen gas with a purity up to 97%.
This generator produces nitrogen by combining the utilization of compressors and Carbon Molecular Sieve (CMS) technology. Its dual compressor technology utilizes both a high and low pressure compressor, both of which are included with the unit. This allows the unit to remain quiet while producing a constant, uninterrupted N2 gas supply.
This 2-stage pressure design also reduces the stress on the compressors, extending their life and reducing maintenance costs. This generator is able to produce nitrogen at both a low pressure and ambient temperature, eliminating the need for hazardous high pressure cylinders and liquid Dewars. The NITRO-GEN+ promotes a safe laboratory environment while being a reliable source of N2 gas for a variety of applications.
Download the product brochure
Video Demonstration
Standard Features:
- Integrated low noise, oil free compressors
- On-demand nitrogen supply 24/7
- Proprietary carbon molecular sieve technology
- Complete "plug and play" LC-MS solution
- Two year complete product warranty or 8,000 hour run-time warranty
Specifications:
- Flow rate up to 35 L/min
- Purity up to 99% with a flow rate less than or equal to 25 L/min
- Purity up to 98% with a flow rate greater than 25 L/min
- Dewpoint -58 °F/-50 °C
- 20 minute warm-up time
- Output pressure 0-16 psi/0-8 bar
- IP20 Index of Protection
- IK08 Mechanical Impact Rating
- Noise level 55 dBa at 1 meter
The NITRO-GEN+ is brought to you in partnership with VICI DBS.
Contact us now to learn more about this generator!
