    AMR-100 Microplate Reader

    Product Description


    AMR-100 Microplate Reader is a reliable and robust instrument for a wide variety of research and clinical applications. It reads various kinds of 96-wells plates and equipped with shaking function. It can be used as a stand alone instrument or under PC control with regular or APP software. The software is easy-to-use..

    AMR-100 Microplate Reader is a 9-channel absorbance microplate reader that provides not only accurate, reproducible and fast measurements, but also offer innovative design with its easy-to-use control and data analysis software. It is ideal for a variety of ELISA applications in the biology laboratory
    1. Easy of use with 7 inch touch screen together with 3 external keys
    2. A broad wavelength range of 340-750nm
    3. Able to use individually or connect with PC and export results
    4. Absorbance range: 0.0~4.000Abs
    5. 8 positions optical filter wheel, equipped with 4 standard optical filters
    6. Rapid and accurate measurement of 96-well plates within 6 seconds
    7. 9-channel ELISA reader for fast measurements
    8. Additional reference channel for optimized light intensity
    9. Endpoint, kinetic and multi-label measurements for a variety of applications
    10. Shaking with variable time and speed.
    11.PC software, APP software and bulit-in software for powerful and validated data analysis.


    AMR-100 Highlights​

    1. Easily use with 7 inch touch screen together with 3 external keys.

    2. It keeps with high visual and logical user ​interface of software,it can be offered a comprehensive inbuilt calculations, such as blank subtraction, quantitative curve fit, quanlitative classification and kinetic calculations, as well as the versatile reporting tool and make data reduction.


    Product Image



    Technical Parameters


    Display 7 inch touch screen (800x480 dots)
    Light source Quartz-halogen lamp 6V/10W
    Wavelength 340-750nm
    Optical filter Equipped with filters: 405,450,492,630nm
    Half-bandwidth of filters 8~10nm
    Read-out range 0~4.000Abs
    Linearity (405nm) (0~2.000Abs) ≤±1%, [2~4.000Abs) ≤±2%
    Resolution 0.001Abs
    Accuracy (405nm) ±1% (0-3Abs); ±3% [3-4Abs)
    Precision(405nm) CV≤0.2% (0-3Abs): CV≤1% [3-4Abs)
    Test speed <6s for 96 wells plate
    Incubator No
    Shaking 3 modes shaking: slow, medium and fast
    User interface Integrated software or PC control software
    Operation Touch screen, 3 pcs external keys
    Storage 200 programs and 1000 test records
    Ports 3 USB ports, for PC, printer and USB-disk
    Power supply AC100-240V, 50-60Hz, 2A
    Dimensions (W x D x H) 440 x 295 x 225 mm
    Weight (kg) 10Kg
    bio-equip.cn
    Professional manufacturer of Laboratory equipment:
    Drying Oven, Incubator, Heating Mantle, Magnetic Stirrer, Water Baths, Laminar Flow Cabinet, Furnace, Autoclave, Claminar Chamber, Plant Growth Chamber and etc.

    All our FAITHFUL products have passed the CE Certificate.
