- AMR-100 Microplate Reader
Product Description
AMR-100 Microplate Reader is a reliable and robust instrument for a wide variety of research and clinical applications. It reads various kinds of 96-wells plates and equipped with shaking function. It can be used as a stand alone instrument or under PC control with regular or APP software. The software is easy-to-use..
AMR-100 Microplate Reader is a 9-channel absorbance microplate reader that provides not only accurate, reproducible and fast measurements, but also offer innovative design with its easy-to-use control and data analysis software. It is ideal for a variety of ELISA applications in the biology laboratory
1. Easy of use with 7 inch touch screen together with 3 external keys
2. A broad wavelength range of 340-750nm
3. Able to use individually or connect with PC and export results
4. Absorbance range: 0.0~4.000Abs
5. 8 positions optical filter wheel, equipped with 4 standard optical filters
6. Rapid and accurate measurement of 96-well plates within 6 seconds
7. 9-channel ELISA reader for fast measurements
8. Additional reference channel for optimized light intensity
9. Endpoint, kinetic and multi-label measurements for a variety of applications
10. Shaking with variable time and speed.
11.PC software, APP software and bulit-in software for powerful and validated data analysis.
AMR-100 Highlights
1. Easily use with 7 inch touch screen together with 3 external keys.
2. It keeps with high visual and logical user interface of software,it can be offered a comprehensive inbuilt calculations, such as blank subtraction, quantitative curve fit, quanlitative classification and kinetic calculations, as well as the versatile reporting tool and make data reduction.
Product Image
Technical Parameters
| Display | 7 inch touch screen (800x480 dots) |
| Light source | Quartz-halogen lamp 6V/10W |
| Wavelength | 340-750nm |
| Optical filter | Equipped with filters: 405,450,492,630nm |
| Half-bandwidth of filters | 8~10nm |
| Read-out range | 0~4.000Abs |
| Linearity (405nm) | (0~2.000Abs) ≤±1%, [2~4.000Abs) ≤±2% |
| Resolution | 0.001Abs |
| Accuracy (405nm) | ±1% (0-3Abs); ±3% [3-4Abs) |
| Precision(405nm) | CV≤0.2% (0-3Abs): CV≤1% [3-4Abs) |
| Test speed | <6s for 96 wells plate |
| Incubator | No |
| Shaking | 3 modes shaking: slow, medium and fast |
| User interface | Integrated software or PC control software |
| Operation | Touch screen, 3 pcs external keys |
| Storage | 200 programs and 1000 test records |
| Ports | 3 USB ports, for PC, printer and USB-disk |
| Power supply | AC100-240V, 50-60Hz, 2A |
| Dimensions (W x D x H) | 440 x 295 x 225 mm |
| Weight (kg) | 10Kg |
-
