Reliability and Key Features
High efficiency specially compressor with known field proven reliability.
Permanently lubricated cooling fan for safety and longevity.
Forced-air cooling with optimized air distribution system designed.
To achieve maximum temperature uniformity and stability.
Optimized refrigeration system design for more effective cooling and speedy recovery.
Temperature variation within ±3℃.
Adjustable temperature range 2-8℃.
Microprocessor control digital display, and temperature adjustment with an increment of 0.1℃.
Large digital display screen.

Characteristic Function
Safety door lock design to avoid door ajar.
Big digital screen display for easy observation.
Optional testing hole.
Adjustable shelves.
Inner light design for a clear display.

Safety
Equipped with a complete temperature alarm system featuring audible buzzer and visible flashing light.
Capable of alerting failures due to high and low temperature sensor error, door ajar, power failure and low battery.

Forced Air-cooling System
Advanced forced cooing system to keep inside temperature stable and uniform. Finned evaporator with special cycle design of forced air cooling system to ensure no-frost inside.

Ergonomic Design
Optimized space utilization design with multi-level and adjustable shelf height to accommodate storage requirement of pharmaceutical products of various kinds.
Safety lock to prevent unauthorized access.
Caster design and leveling legs LED interior light.

	Model	PR5-320
Specifications	Shelf/drawer	Shelves/5
	Cooling method	Forced Air Cooling System
	Defrost	Auto
	Refrigerant	R290
	Power consumption(kWh/24h)	1.78
	Noise(db)	50
	Ambient temperature(℃）	10~32℃
	Temperature range(℃）	2~8℃
Cooling system	Compressor brand/QTY	China Brand/1
	Sensor Type	NTC
	Temperature controller	Microprocessor
	Display	Digital display
Power	Voltage/frequency（V/Hz)	220/50Hz
	Power(W)	240W
	Current(A)	1.2A
Material	Inside material	Color sprayed steel
	Outside material	Color sprayed steel
	Insulation	PURF
Size	Capacity(L/cu.ft)	316/11.15
	NW./GW.(kg)	92.5/100
	Exterior size(W×D×H)(mm)	660×555×1915
	Interior size(W×D×H)(mm)	540×425×1380
	Package size(W×D×H)(mm)	710×640×1970
	CBM	0.9
	20GP/40GP/40HQ	27/54/54
Alarm	High/low temperature	Y
	Power failure	Y
	Thermostat failure	Y
	Backup battery failure alarm	/
	Condenser fault alarm	/
	Ambient Temperatures	/
	Voltage abnormality alarm	/
	Door ajar	Y
	System abnormal alarm	/
	Power failure backup system(alarm)	8h
Accessories	Foot	Y
	Castor	Y
	Outer door/Type	1/Glass /Low-E
	Door Lock	1
	Test hole QTY/diameter	1/25mm
	Lamp	LED
	USB port	/
	Temperature recorder	Optional
	Remote alarm port	Y
	RS232/485 port	/
