- M48 Nucleic Acid Extraction System
- Product Detail
- Company Profile
- Product Information:
Based on magneticbead adsorption and separation automated extraction method, M48 NucleicAcid Extraction Systems could overcome the disadvantages oftraditional nucleic acid extraction methods, and achieve an rapid, efficientpreparation of 48 samples at a time. With corresponding nucleic acidextraction reagents, it can process various sample types suchas serum, plasma, whole blood, swabs, feces, tissues,
paraffin sections, bacteria, fungi, etc., and used for disease preventionand control, animal quarantine, clinical diagnosis, entry-exit inspectionQuarantine, Food and Drug Administration, Forensic Medicine, Teachingand Scientific Research
Features
1.Built-in UV disinfection module and negative pressure exhaust filter module, highly effective anti-pollution;
2.Open platform: suitable for multiple nucleic acid extraction schemes based on nano-magnetic beads;
3.Precise temperature control, fully reduce the volatilization of the eluent;
4.Automated nucleic acid extraction experiments, 48 samples can be processed at one time;
5.1-10 level mixing speeds are available, custom mixing mode.
Instrument parameters
| Product name | M48 Nucleic Acid Extraction System |
| Model | M48 |
| Sample throughput | 1-48 |
| Volume | 20-1000 pL |
| Consumable | 96-well deep plate + magnetic rod cover |
| Recovery | 298% |
| Purification hole difference(CV) | <5% |
| Operation humidity | 30%~80% |
| Operation temperature | 10°C~40°C |
| Heating temperature | 4°C~120°C |
| Vibration | 1-10 level adjustable, custom mixing mode |
| Disinfection and decontamination | UVXNegative pressure exhaust filter |
| Reagent type | Magnetic bead nucleic acid extraction reagent |
| Interface | Embedded integrated touch screen operation |
| Program management | New, edit and delete, free and flexible editing and extraction programs |
| Connector | USB |
| Dimensions | 500 mm(L)x460 mm(W)x540 mm(H) |
| Power | 100-199VAC 11A/200-240VAC 6.5A, 50/60Hz |
| Net weight | 40kg |
Order information
| Cat. # | Description | Qty. |
| NAES-48 | M48 Nucleic Acid Extraction Systems | 1EA/Box |
-
