Product Description

This machine uses a streamlined design, with advanced features, stable and reliable performance and ease of use

Features:

* Large-volume removable waste tray on the top of housing, convenient to use.

* Imported cross-roller guide rails andhigh-precision screw motion mechanism.

* Fast switching between paraffin block clamp and cassette clamp.

* Hand-wheel balance can be precisely adjustedand can be locked at any position,

* Blade holder can be laterally movedwithout direct contact,enabling use of the entire length of the blade. (three different segments)

* The red bar on the blade holder covers the whole length of blade to protect the user

* Automatic sectioning speed is adjustable. (BK-2498only)

* Auto slicing controller ensures trimming and slicing switching easily; When it is off, semi-auto slicing or trimming is

available.(BK-2498only)

* Safety and emergency braking systems (BK-2498 only)，security alarm systems, driver-overload protection and auto-sleep protection system.(For all 3 models)

* Control system with 3 modes: conventional mode, intelligence sensing mode and whole layer cutting mode.(BK-2488 only)

Specification

Model	BK-2478		BK-2488	BK-2498
Mode	Semi-automatic without intelligent sensing		Semi-automatic with intelligent sensing	Automatic or Manual Mode without intelligent sensing
Function	Sectioning, trimming, fast forward, fast backward, quick conversion; automatic retraction (exceptBK-2478).
Retraction Range	/		0~50μm ( If 0 is set, retraction function is off ) 5~50 (Retraction distance is optional in this range, and increment is 5μm, such as, 5, 10, 15, 25...)
Display	LCD Display: sectioning thickness, trimming thickness, slice count.		OLED Display: sectioning thickness, trimming thickness, slice count.	LED display: sectioning thickness, trimming thickness, slice count, slice speed.
Sectioning Thickness Range	0~60μm 0~1.0μm increment 0.25μm 1~10μm increment 1μm 10~20μm increment 2μm 20~60μm increment 5μm		0.25~100μm 0.25~2.5μm increment 0.25μm 2.5~5μm increment 0.5μm 5.0~10μm increment 1μm 10~30μm increment 2μm 30~60μm increment 5μm 60~100μm increment 10μm
Trimming Thickness Range	0 ~60, 0~100, 1~900μm 1~10μm increment 1μm 10~20μm increment 2μm 20~100μm increment 5μm 100~900μm increment50μm		1~600μm 1~10μm increment 1μm 10~20μm increment 2μm 20~50μm increment 5μm 50~150μm increment 10μm 150~600μm increment 50μm
Whole Layer Clearance Distance(Only for BK-2488)	10~6000μm (10, 12, 15, 20.....6000, after 15μm, the increment is 5μm)
Specimen HorizontalStroke	28mm
Specimen Vertical Stroke	52 mm		70mm
Specimen Orientation	XY – 8°, rotation 360°	XY – 8°, rotation ±90°
Mini. Sectioning Thickness	0.25μm
Max. Specimen Size	50*70mm	70*70mm
Feed Speed	450μm/s	1500μm/s,3500μm/s
Precision	±5%
Standard Accessory	Cassette Clamp or Paraffin Block Clamp(Paraffin BlockClamp is acquiescent)
Consumption	100W			150W
Power Supply	AC110/220V±10%, 50/60Hz
External Size(WDH)	585410305mm	575420330mm		580475340mm
Package Size(WDH)	670550480mm	670550480mm		680570500mm
Gross Weight	45kg	45kg		60kg

-------------------------------------------------------------------------------------
