- BIOBASE 200T/H Blood Testing Open Automated mini Biochemistry Analyzer
- Product Detail
- Company Profile
BIOBASE Auto Chemistry Analyzer
Why you choose BK-200mini?
1. Revolutionary alternative for semi auto chemistry analyzer
2. Constant speed: 200 test/hour
3. Small size: save shipping cost
4. Water consumption: 2-3L/H
5. Cross contamination < 0.05%
6. Expanding sample capacity and efficiency for small clinic
Main Features:
1. 37 Sample positions.
2. 28 Reagent positions.
3. 48 Reaction cuvettes.
4. 200 tests per hour.
Parameters:
|
Overall
Performance |
Model
|
BK-200
|
|
Throughput
|
200 Tests/hour
|
|
|
Analysis Method
|
End-point, Fixed-time, Rate(Kinetic)
|
|
|
Sample &
Reagent System |
Sample Positions
|
37 sample positions
|
|
Reagent Position
|
28 reagent positions
|
|
|
Sample Volume
|
2~70μl
|
|
|
Reagent Volume
|
20~350μl
|
|
|
Probe
|
Liquid level sensor function, anti-collision function.
|
|
|
Probe Washing
|
Automatic washing interior and exterior
|
|
|
Reagent Cooling
|
Refrigerated tray with independent switch
|
|
|
Reaction System
|
Temperature Control
|
37+0.1℃, real-time monitoring
|
|
Cuvettes
|
48 reusable cuvettes,optical length 6mm
|
|
|
Mixer Probe
|
Independent stirring
|
|
|
Washing
|
Automatic cuvettes washing
|
|
|
STAT function
|
YES
|
|
|
Optical System
|
Light Source
|
6V/10W halogen lamp
|
|
Spectrophotometry
|
Post-spectral spectrophotometry
|
|
|
Wavelength
|
340,405,450,510,546,578,630,700nm
|
|
|
Absorbance
|
0~3.0Abs
|
|
|
Calibration & QC
|
Calibration
|
Linear:K factor, 1-point ,2-point and multipoint liner Non-Linear:Spline,Polygon,Index,Ogarithm,Logit-4P, Logit-5P
|
|
Quality Control
|
Real-time QC, Westgard multi rule,
Cumulative Sum Check,Twin Plot(2D) |
|
|
Data Management
|
Software
|
Windows 7/8/10 , 32or 64bit
|
|
LIS System
|
Bi-direction,support HL7 protocol
|
|
|
Interface
|
LAN port access
|
|
|
Printer
|
External,multiple reporting mode available
|
|
|
Working Conditions
|
Power Supply
|
AC220V+10%,50/60Hz, 110V+10%,60Hz, 300W
|
|
Temperature
|
10℃~30℃
|
|
|
Water Consumption
|
Deionized water:3L/H
|
|
|
Humidity
|
30-80%
|
|
|
Size & Weight
|
Size (W*D*H)
|
625*425*460mm
|
|
Net Weight
|
36kg
|
|
|
Package Size (W*D*H)
|
721*531*855mm
|
|
|
Gross Weight
|
50kg
|
