SHST SH-Compact 523 ECL imaging system adopts 16-bit Cooling CCD camera and large aperture lens, provides ultra-high sensitivity and resolution, brings you perfect Western blot images!

Video at Youtube

Features

Make Western Blot easy to go

To conduct Western blot experiments in a tranditional way, we usually use X-film exposure in the darkroom. Such method not only requires the researcher to anticipate the exposure time, but also touch the toxic regents inevitablely. Furthermore, the dynamic range of the X-film image is too narrow to show the weak and strong bands on the same image easily.

Extreme Sensitivity and high resolution

The system adopts 16 bit cooled CCD Camera, wich provides:

1. 6.05 Megapixel

2. Cooling temperature: -60℃ below ambient

3. Quantum Efficiency up to 75%

Devoted to Chemiluminescence application with ECL

SH-Compact 523 ECL imaging system is especially designed for chemiluminescence with ECL. It is suitable for ECL, ECL Plus, Western lightning and other luminescent substrates.

Easy update available

The system can be updated easily to a multifunctional imaging system, which is capable for gel documentation, fluorescent imaging application.

Specifications

CCD Camera

16 Bit Cooled CCD Camera
CCD Size：12.49x9.99mm
CCD Sensor：Sony ICX695
Pixel Size：4.54μmX4.54μm
Readout noise: 5.5e- RMS at 12 MHz
Dark Current: <0.0005 e-/pixel/sec. @ -40º C
Dynamic range: ﹥4.6 OD
Resolution：6.05 Megapixel，2750*2200
Grey Scales： 16bit (65536 Grey scales)
Quantum Efficiency： >75%
Cooling Temperature：(TEC) -60℃ below ambient

Lens

F/0.95 motorized lens
Controlled by software

Light Source
A pair of white LED
