SHC Series Hydrogen Generator
SHC-300/SHC-500
Product introduction:
SHC series hydrogen generator is to electrolysis KOH liquid to produce hydrogen. There are many intelligent control equipments inside of equipment, easy and safety. The equipment could meet requirement of many kinds of gas chromatograph at home and abroad.
Working Principle:
The operational principle of this instrument is traditional electrolyzing lye. The conducting medium in the cell is water solution of KOH. The membrane between the two electrode chambers is for the navigation electrolysis equipment. After electrifying direct current, the electrochemical reaction of water molecule occurs. It produces oxygen on the anode, and hydrogen on the cathode. The reaction equation is as follows:
Anode: 2OH--2e → H2O 1/2O2↑
Cathode: 2H2O 2e → 2OH- H2↑
Final reaction equation: 2H2O → 2 H2↑ O2↑
The pressure control, protective pressure, flow display and flow tracking are all automatic control. The hydrogen output is self-regulation according to the using hydrogen flow under stable pressure (in the range of output flow).
Features and Advantags
1.Easy to operate, safe and reliable, adding lye only for one time, only replenishing distilled water, switching power on to produce gas(available for several sets of gas chromatography)
2.Device for preventing backflow of lye.
3.Drum-shaped electrolysis cell, high-grade stainless steel 316L used as material for electrolysis cell.
4.High electrolysis efficiency. Gas purity and output flow will stay regular under continual use.
Technical Parameter:
| Type | SHC-300 |
| Output Volume (ml/min) | 0~300 |
|
Output Pressure (MPa) |
0.15~0.4 |
|
H2 purity (%) |
>99.9995 |
|
Protective Pressure (MPa) |
0.46 |
|
Power Voltage (V) |
220±15% 110±15% 50~60Hz |
|
Input power (W) |
<150 |
|
Dimension (LxWxH) mm |
431x228x343 |
|
Net Weight (KG) |
< 15 |
-
Shandong Saikesaisi Hydrogen Energy CO., Ltd. is a high-tech and strong innovation team. She has being engaged in producing PEM/SPE Hydrogen Generator from 1992. The chief technical expert is the first one developing PEM/SPE technology in China who has developed Four generation hydrogen generators and some have won the patens and fill in the vacancy in Chinese technology field.
The company choose SPE-Solid Polymer Electrolyte positive ion(proton) exchange membrane to electrolyze pure water which replaces traditional alkali liquor hydrogen production. This technology has won BECIA golden medal and certificate of patent.
Because of good quality, some products have got CE certification(No.E/EC13840511537). Now this company can supply the following products:
1.QL Series Hydrogen Generators (0-34000 ml/min).
2.SHC Series Hydrogen Generators(0-500 ml/min).
3.QL Series Pure Air Generator(0-300 l/min).
4.QL Series Nitrogen Generator(0-500 l/min).
5.QL Series Nitrogen and Air Generator(Nitrogen:0-300 ml/min, Air:0-1000 ml/min), Nitrogen, Hydrogen and Air Generator(Nitrogen:0-300 ml/min, Hydrogen:0-300 ml/min and Air:0-1000 ml/min).
6. Other customized generator and Accessory parts.
