BT102S Micrometeor Speed -Variable Peristaltic Pump

1.Four-figure digital LED indicator display working speed ;

2.Intelligent expert operating system can guarantee smooth operation

3.Easy dispensing function ,it realizes the repeat timing quantitative dispensing .

4.Can drive multi-channels and various and various types of pump heads.

5.Stainless steel housing ,easy to clean ,excellent resistance to the corrosion of the acid,alkali,sodium and the organic solvents.

6.Internal double-desk isolation structure ,circuit board with conformal coating makes it dust-proof and moisture-proof.

Technical parameters
• Flow range :0.00011-380ml/min
• Flow accuracy:＜0.5%
• Speed range:0.1-100rpm.
• Speed resolution :0.1rpm
• Power supply :AC 220V±10%,50Hz/60Hz（standard）,
AC 110V±10%,50Hz/60Hz（optional）
• Power consumption：＜30W
• External control：Input electrical level 5V,12V(standard),24V(optional).
• External communication interface：RS485 communication interface，
support the MODBUS protocol.
• Ambient temperature：0 ～ 40℃
• Relative humidity:＜80%
• IP grade:IP31
• Dimensions（LxWxH）218mmx 127mmx122mm
• Weight：2.7KG

peristaltic pump head and tubing matching information

BT102S Pictures of applicable pump head


BT102S（DG-1）	BT102S（DG-2）	BT102S（DG-4）	BT102S（YZ15/25）

BT102S

（304 stainless case ）

DG6-1(6 rollers)

1

Wall 0.8～1，ID ≤3.17

0.00016～49

DG10-1(10 rollers)

1

Wall 0.8～1，ID ≤3.17

0.00011～41

DG6-2(6 rollers)

2

Wall 0.8～1，ID ≤3.17

0.00016～49

DG10-2(10 rollers)

2

Wall 0.8～1，ID ≤3.17

0.00011～41

DG6-4(6 rollers)

4

Wall 0.8～1，ID ≤3.17

0.00016～49

DG10-4(10 rollers)

4

Wall 0.8～1，ID ≤3.17

0.00011～41

YZ15

1

13#14#16#19#25#17#18#

0.006～380

www.leadfluid.com Email:sale@leadfluid.com Skype:anna112296

BT102S （304 stainless case ）	DG6-1(6 rollers)	1	Wall 0.8～1，ID ≤3.17	0.00016～49
	DG10-1(10 rollers)	1	Wall 0.8～1，ID ≤3.17	0.00011～41
	DG6-2(6 rollers)	2	Wall 0.8～1，ID ≤3.17	0.00016～49
	DG10-2(10 rollers)	2	Wall 0.8～1，ID ≤3.17	0.00011～41
	DG6-4(6 rollers)	4	Wall 0.8～1，ID ≤3.17	0.00016～49
	DG10-4(10 rollers)	4	Wall 0.8～1，ID ≤3.17	0.00011～41
	YZ15	1	13#14#16#19#25#17#18#	0.006～380
