Optional Module
|
96 Module:96wells×0.2ml
9677 Module:96wells×0.2ml+77wells×0.5ml
48 Module:48wells×0.2ml+48wells×0.5ml
108 Module:108wells×0.2ml+88wells×0.5ml
Multi-purpose: 9677 Module + In-situ Adapter
|
Display
|
7” Color Touch Screen, graphical display of protocols and running status
|
Communications
|
USB2.0, LAN and RS232
|
Temperature
|
Block Temperature Range
|
0℃~100℃
|
Max. Heating/Cooling Rate
|
6℃/s
|
Temperature Uniformity
|
≤±0.2℃(at 95℃)
|
Temperature Accuracy
|
≤±0.2℃(35℃-100℃)
|
Display Resolution
|
0.1℃
|
Mode of Temperature Control
|
Sim-tube & Block mode
|
Gradient
|
Gradient Accuracy
|
≤±0.3℃(35℃-100℃)
|
Column Uniformity
|
≤±0.3℃(at 95℃)
|
Gradient Range
|
30℃~99.9℃
|
Temp. Differential Range
|
Max. 30℃
|
Gradient Capability
|
12 Column(Vertical)
|
Heated Lid
|
Height of Heated Lid
|
Steplessly Adjustable Lid, accommodates a wide range of PCR tubes and plates
|
Open Method
|
Innovative "TOP-OPEN" technology realizes Two-in-One(Open/Lift) Lid
|
Heated Lid Temperature Range
|
30℃~112℃
|
Auto Shut-Off
|
Yes
|
Software
|
Max. Number of programs
|
Max. 15,000 programs onboard, unlimited storage of protocols with USB flash drive
|
Max. Step
|
30 Steps, multiple nesting cycle available
|
Max. Cycle
|
100 typical cycles (duplex nesting 60,000 cycles)
|
Time & Temp. Increment/Decrement
|
Yes , available for Long PCR & Touchdown PCR
|
Auto Pause / Auto Restart
|
Yes
|
Multi-user log in
|
With password-based authentication, prevent from view, copy and alteration of protocols
|
Tm calculator
|
Automatically calculates the melting and annealing temperature with two primer sequences
|
Hold at 4℃
|
Yes, an Infinite incubation time at low temperature for overnight working
|
Program wizard
|
Yes, create PCR protocols with only a few clicks
|
Running Report
|
Yes, provide precise data support for analyzing of experimental results
|
PC Connection
|
PC remote control to manage more than 120 units of A300 across the network
|
Other Features
|
Power
|
Universal AC input Switching Power Supply: 85V ~ 265V, 50-60Hz Max. 600W
|
Dimension(L×W×H)
|
362×256×255mm
|
Net Weight
|
7.3kgs
|
