Grey water refers to integrated wastewater used in industrial production, such as chemical, power plants, hazardous waste high temperature treatment, printing and dyeing industries for dust removal, desulfurization, de-smoke, cooling, etc. The significance of grey water treatment is: After treatment, it can meet the standard of process reuse to achieve the goal of minimizing the production of sewage in the production. Reduce the difficulty of the subsequent sewage treatment process and reduce the workload of sewage purification. Take the gray water in hazardous waste high temperature treatment as an example: The flue gas generated by the cinder after high-temperature gasification carries hazardous waste particles and dust, and the cooling water used for cooling in the process finally forms gray water. Today, with the growing demand for environmental protection and increasingly strict environmental protection policies, the handling of industrial hazardous waste has become a top priority. The orders of hazardous waste treatment plants are increasing day by day. With the expansion of their production capacity, the hazardous wastes of various industries are like a world apart. The composition of the gray water produced in the process of production varies greatly. In the traditional gray water treatment process, many hazardous waste treatment plants have selected vacuum belt filtration, plate and frame filter and other equipment for solid-liquid separation of gray water. Both of the above devices intercept the solid particles in the gray water through the filter medium. However, the filtration effect of all the devices using the filter medium is limited by the size of the solid particles and the comprehensibility of the solid.

The smaller the particle size, the less likely it is to capture, and the better the comprehensibility, the more easily the solid particles cause clogging of the filter screen, greatly reducing the filtration effect. As the composition of the gray water changes, the original effective filtration method gradually loses its due effect. The principle of the gray water treatment centrifuge developed by SHENZHOU separation is to use the density difference between the solid phase and the liquid phase in the water, and the high-speed rotation of the drum of the equipment produces a centrifuge that is thousands of times larger than the gravity of the object. The solid and liquid in the water are stratified by centrifugal and then discharged separately through different liquid phase and solid phase outlets. This method is not limited by the gray water component, and adopts fully automatic control with variable frequency modulation to set different gray water for different industries.

The parameters have a solid removal rate of over 98%.The equipment has small footprint, low energy consumption, fully automatic control, and can be easily operated by one person. The fully enclosed design makes it have excellent working environment, low noise, low vibration and low maintenance cost. It is widely used in power plants and chemical industry. Gray water treatment in factories, printing and dyeing plants, the effect is remarkable.

Model	Technical parameter					motor power		outline dimension(mm)	Machine weight (KG)
	(Diameter)mm	Rotation speed rpm	Length mm	Separation factor G	capacity M3/h	Main motor KW	Vice motor KW	Dimension: L×D×H
	(Diameter)mm	Rotation speed rpm	Length mm	Separation factor G	capacity M3/h	Main motor KW	Vice motor KW	Dimension: L×D×H
LW250×1000	250	3600	1000	1813	1-3	7.5/11	4/5.5	2065×1050×800	1100
LW360×1200	360	3500	1200	2467	3-8	11/18.5	7.5/11	2600×1500×850	1900
LW360×1500	360	3500	1500	2062	3-8	11/18.5	7.5/11	2800×1400×850	2000
LW420×1750	420	3200	1750	2406	4-20	30/37	11/18.5	3120×1580×1050	3000
LW450×1600	450	3200	1600	2578	5-25	30/45	11/22	3780×1050×1180	3500
LW450×1800	450	3200	1800	2578	5-25	30/45	11/22	3985×1050×1180	3600
LW450×2000	450	3000	2000	2266	5─25	30/45	11/22	4320×1050×1180	3800
LW500×1800	500	3000	1800	2517	10-30	37/55	15/22	4200×1110×1200	4300
LW500×2100	500	3000	2100	2517	10-30	37/55	15/22	4500×1110×1200	4500
LW550×1800	550	3000	1800	2769	10-35	45/55	18.5/22	4380×1160×1230	4800
LW550×2200	550	2800	2200	2412	10-35	45/55	18.5/30	4780×1160×1230	5000
LW650×1750	650	2000	1750	1454	20-50	75/90	30/37	4576×1300×1250	6000
LW650×2000	650	2000	2000	1454	20-50	75/90	30/37	4900×1300×1250	6200
LW800×2000	800	1800	2000	1450	40-100	90/110	45/55	6052×1460×2100	10000
LW1000×2350	1000	1600	2350	1432	50-140	110/132	55/75	6850×1860×2300	12800
