DLS-802 dynamic light scattering nanometer particle size analyzer which based on the dynamic light scattering principle, the first manufacturer which use digital correlator in China. It was upgraded from DLS-801 which is the first set of nanometer particle size analyzer in China. Based on Brownian motion principle, smaller particle, faster speed, bigger particle, more slowly. It adopts great performance of Japan HAMAMATSU photomultiplier and self-developed high speed digital correlator as core parts, get diffusion coefficient by test scattering light change in some angles, and calculate particle diameter and distribution according to stokes-Einstein equation. the machine is with characters of fast calculation, high resolution ration, good accuracy, and repeatability, therefore it’s widely used in company product lab research and university.

Specs		DLS-802
Standards		GB/T 19627-2005/ ISO 13321:1996 GB/T 29022-2012/ ISO 22412:2008
Measure range		1nm - 10000nm
Concentration range		0.1mg/ml - 100mg/ml
Accuracy error		<1% (CRM D50)
Repeatability error		<1% (CRM D50)
Light source		Semiconductor laser λ= 532nm P=30mW
Detector		Imported Japan HAMAMATSU photo-multiplier (19-90℃)
Scattering angle		90^o
Sample cuvette		1-4mL
Test temperature		5-40 ℃ (temperature controller 5-90℃, precision within 0.1℃)
Test speed		<5 Min
Power Supply		220V 50Hz/ 60Hz
Outer Dimension		L48cm * W27cm * H17cm
G.W.		12 Kgs
Operation system		Win XP/ Win 7/ Win 10, 64 bits, USB port: 2.0 /3.0
Analysis		Average particle diameter, particle distribution, photon counting rate etc.
Analysis mode		NNSL, multi-peak and CONTIN
Digital Correlator	Model	CR256
	Auto-correlation channels	256
	Baseline channel	4
	Physical channels	5000
	Unit delay time	100ns-10ms
