CE Digital Heating Mantle, Magnetic Stirrer Heating Mantle
Up to 450 ºC general heating equipment.
Uses:
It applies to colleges, petrochemical industries, medicine, and environment protection institutions for liquid heating and stirring.
Product Description:
1. PID Single Screen Temperature controller.
2. Heating and Stirring can be used simultaneously, stepless speed adjustable.
3. PT100 Temperature sensor, with Adjustable Sensor Rack and Stainless Rods.
Main Technical Parameters:
|
Model
|
98-I-AB
|
|
Function
|
Capacity(ml)
|
50
|
100
|
250
|
500
|
1000
|
2000
|
3000
|
5000
|
10000
|
20000
|
|
Heating Mode
|
Surface heat-conduction
|
|
Surface Max. Temp.( ºC)
|
450ºC
|
|
Temperature control range
|
RT+20~250ºC
|
|
Speed range
|
0~1600rpm
|
|
Structure
|
Heating element
|
Nichrome wire
|
|
Stir bar
|
PTFE
|
|
Shell(Insulation Layer)
|
Cold- rolled steel plate, surface spraying
|
|
Motor power
|
0.01kW
|
|
Heating power (kW)
|
0.1
|
0.1
|
0.2
|
0.3
|
0.35
|
0.5
|
0.6
|
0.8
|
1.2
|
2.5
|
|
Controller
|
Working mode
|
Continuous
|
|
Specification
|
Exterior size (mm)
|
¢220×165
|
¢285×210
|
¢330×230
|
¢340×245
|
¢350×250
|
¢425×320
|
¢470×340 |
|
Packing size (mm)
|
230×230×230
|
300×300×270
|
330×330×280
|
360×360×300
|
390×390×310
|
380×380×330
|
510×510×380
|
|
Voltage(V)
|
100~120V or 200~240V
|
200~240V
|
|
N.W. (Kg)
|
2.1
|
3.5
|
4.5
|
7.5
|
8
|
9.8
|
16
|
|
G.W. (Kg)
|
2.5
|
4.2
|
5.2
|
8
|
9.2
|
12
|
20
|
