Overview
Quick Details
Type: Genes & Life Science Equipments Brand Name: Molarray
Model Number: MA-6000 Place of Origin: Jiangsu, China
Instrument classification: Class III Warranty: 1 Year
Certificate: CE ISO9001 ISO13485 Function: DNA Analysis
Display: Connect to PC Weight: 23KG
Power Supply: 100-240V 50/60Hz Size: 60CM(L)*39CM(W)*32CM(H)
Sample Volume: 20ul ~120ul Package: Carton+EVA+Wooden Case
Application: Hosipital, clinical detection, laboratory, animal husbandry
After-sale Service: Online technical support
Main Applications
* Basic scientific research
* Pathogen detection
* Public health safety epidemic monitoring
* Adulteration of meat products
* Genetically Modified testing
* Food safety testing
* Drug development and rational use
* Tumor precision treatment
* Gene expression
* Genetic screening
* Genotyping
* Stem cell Research
Product Features
(1) Highly sensitive and capable for most experiments.
(2) 6 independent and intelligent temperature control technology with full light spectrum halogen lamp as excitation light source.
(3) 96 x 0.2 ml reaction module, 5 fluorescent channels, suitable for most of the practical applications.
(4) So easy and quick to operate one to ten machines only by one computer in the meantime.
Performance Parameters
|
Configuration
|
96 wells of 0.2 ml each, suitable for single tube and 8 tube strips
|
|
Heating and cooling module
|
Peltier semiconductor thermoelectric module, dual independent temperature control and smart thermal compensation technology, fast and uniform heating and heat dissipation, uniform temperature among wells and no heat fringing effect.
|
|
Temperature modulation range
|
4℃ ~ 100℃
|
|
Ramp rate
|
3.5℃/s
|
|
Damp rate
|
3.2℃/s
|
|
Temperature control accuracy
|
±0.1℃
|
|
Uniformity of temperature control
|
±0.25℃
|
|
Fluorescent channels
|
5 channels
|
|
Excitation light spectrum
|
380nm ~ 780nm
|
|
Detection light spectrum
|
380nm ~ 780nm
|
|
Number of filter combinations
|
Custom
|
|
Excitation light source
|
Halogen lamp
|
|
Detection device
|
-20℃ CCD
|
|
Fluorescence conduction mode
|
Space dedicated optical fiber
|
|
Supported dye
|
Full range of fluorescent quantitative PCR reagents or customized
|
|
Reaction volume
|
20-120 μl
|
|
Control mode
|
Connect to PC
|
|
Detection number
|
Up to 480 samples in one run
|
|
Detection sensitivity
|
10~10⁹ copies per reaction, without contaminants among samples
|
|
Software function
|
Absolute quantification, relative quantification, end-point genotyping (Taqman probe method); melting curve genotyping (hybridization probe method), Tm value determination, and melting curve analysis function.
|
|
Operating temperature
|
18℃~35℃
|
|
Storage temperature
|
20℃~55℃
|
|
Ambient relative humidity
|
0%~85%
|
|
Working voltage
|
100~240V, 50~60HZ
|
