Section thickness range： 1-100μm Adjustable ，
1-20μm ， Increment：1μm；
0-40μm， Increment：2μm；
40-100μm， Increment：5μm；
Trimming thickness range： 10-400μm Adjustable，
10-50μm ， Increment：5μm；
5-100μm ， Increment：10μm；
100-400μm ， Increment：50μm；
Specimen retraction： 0-80μm Adjustable ，Increment：5μm
Maximum specimen size： 45mm×50mm
Horizontal stroke： 20mm
Vertical stroke： 60mm
2.Chamber temperature： -10℃～-40℃ Adjustable
Specimen head temperature： -10℃～-40℃ Adjustable
3.Freezing shelf ：Minimum Freezing shelf temperature： -45℃
Number of freezing station： 26
4.Peltier ：Minimum Peltier shelf temperature： -60℃
Peltier number： 2
Working time to reach -60℃： 15min Size：660mm*640mm*1150mm 135kgs
Packing size：790mm*810mm*1336mm 175kgs
-
Established in 2007, Jinhua Huiyou Equipment And Instrument Co., Ltd. is a manufacturer and trader specialized in the research, development and production of Medical Devices.
We are located in Jinhua, Zhejiang, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
